Experimental Study of Steel Reinforcement Repair Sleeve on X80 Pipe with Interlayer Defect

Abstract:

This paper introduces characteristics of common repairment method for oil and gas transmission pipeline, especially for steel reinforcement repair sleeve. In this research, an X80 pipe with interlayer defects repaired by steel reinforcement repair sleeve was studied. In order to investigate the repair effect of steel reinforcement repair sleeve for interlayer defects, a hydraulic blasting test and metallographic analysis for repaired pipeline were performed. The result shows that interlayer defect influences the pressure capacity of pipe to a certain degree, however, steel reinforcement repair sleeve could provide an acceptable strengthening to the repaired section.

• Periodical: Materials Science Forum (Volume 1035)
• Pages: 452-457
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.1035.452
• Online since: June 2021
• Authors: Lin Wang*, Jin Gao, Ming Chang Wu, Zhi Yu, Qiang Ma
• Keywords: Interlayer, Metallographic Analysis, Pressure Capacity, Steel Reinforcement Repair Sleeve, X80 Pipe

References

[1] Rongguang Li, Juan Du, Guoxing Zhao, et al. Overview of Long Distance Oil/Gas Pipeline Defects and Repair Technology [J]. Petroleum Engineering Construction, 2016, 42(1): 10-13.

[2] Guojian Yu. Comparative Study of Repair Technology for External Corrosion Defects of Long Distance Transportation Pipelines. Pipeline Technique and Equipment, 2013 (1).

[3] Xin Ma, Research on risk analysis of on-duty long-distance pipeline [D]. Lanzhou University of Technology, (2005).

[4] Fanhui Zhang, Risk Assessment around Transmission Pipeline Carrying Petroleum and Gas [D]. Ocean University of China, (2008).

[5] Yumei Wang, Yanshuang Liu, Yanping Zhang, et al. A General Review: Rehabilitation Technology of Oil and Gas Pipelines at Abroad [J]. Oil & Gas Storage and Transportation 2005, 24(12): 13-16.

[6] Yan Li, Zongming Yuan, Shiqiang Hu. Development and Current Situation of Repairing Technology for Long Run Piping [J]. Process Equipment & Piping. 2007 (1): 53-55.

[7] Xiaomei Hu. Reinforcing Effect Research of Pressure Pipeline Reinforced by Carbon Fiber Sheet [D]. Southwest University of Science and Technology, (2015).

[8] Jie Chen. Numerical Simulation and Experiment on Pipes Repair by Steel Sleeve Filled with Epoxy Resin [D]. Southwest Jiaotong University, (2014).

[9] Wenying Hui, Jianzhuang Niu, Jiangfeng Hu, et al. Influential Factors for Pipeline Defects Repairing with Composite Materials [J]. Oil & Gas Storage and Transportation. 2017 (7).

[10] API 5L Specification for Line Pipe.

[11] Li Yi, Ning Mei, Zheng Jian-hua, Dou Zhi-chao, Li Zhi-qun. Study on the Properties of Nonmetallic Inclusions in Seamless Pipes [J]. Metallurgical Analysis, 2012, 32(10): 21-29.

[12] Li Hong-sheng, Gao Hui. Form of Manganese Sulphide Contained in Steel and Influences upon Steel Property [J]. CFHI Technology, 2004 (04): 26-28.
