Modeling the Deformation of Non-Rigid Shafts during Turning on CNC Machines

Abstract:

The purpose of this work is to increase the productivity and accuracy of processing long-length parts of the "shaft" type on CNC machines. Based on the analysis of existing methods for improving the accuracy of processing long shafts on CNC machines, a new method for controlling the spatial error of processing long shafts by changing the processing modes was proposed. The proposed method allows, by changing the processing modes, namely feed, to reduce the radial component of the cutting force and reduce the amount of deflection when machining parts on CNC machines. A technical and economic analysis and justification of scientific research was carried out. The economic effect of the proposed method.

• Periodical: Materials Science Forum (Volume 1037)
• Pages: 309-314
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.1037.309
• Online since: July 2021
• Authors: Nikita P. Matseyn*, Nikolay V. Nosov
• Keywords: Ansys, CNC Machine, Cutter Feed, Cutting Force, Depth of Cut, Finite Element Model, Inflexibility, Machining Conditions

References

[1] Zhdanov, A. A., Plotnikov, A. L., Chigirinsky, Yu. L., Approaches to ensuring the accuracy of turning non-rigid shafts on CNC machines, Collection of scientific works of SWorld. Issue 1: [Mater. international scientific research.- practical conf. Modern trends in the theory. and applied. Research '2014,, Odessa, March 18-30, 2014] Vol. 8 (2014) 96-100.

[2] Drachev O.I., Bobrovskii A.V. The Automatic Stabilization Systems of the Non-Rigid Shafts in Turning Work. Paper presented at the AER-Advances in Engineering Research (2018)158.

DOI: 10.2991/avent-18.2018.20

[3] Balakshin, B. S., Adaptive control of machine tools, M.: Mashinostroenie, 1973, 688p.

[4] Vasin S. A. a Device for turning non-rigid parts, RF Patent No. 2226140. (2002).

[5] ANSYS 12 Theory Reference, LS-DYNA User's Guide, SAS IP, Inc., (2009).

[6] T. Childs, K. Maekawa, T. Obikawa, Y. Yamane. Metal Machining. Theory and Applications, University of Leeds, UK, Ibaraki University, Japan, Tokyo Institute of Technology, Japan, Hiroshima University, Japan, 2000, 410.

[7] Drachev, O., Bobrowskii, A., & Zotov, A. Improving the accuracy of machining of non-rigid shaft, MATEC Web of Conferences, 224 (2018).

DOI: 10.1051/matecconf/201822401085

[8] Maekawa, K. and Maeda M. Simulation analysis of three-dimensional continuous chip formation processes – FEM formulation and a few results. – Japan Soc. Prec. Eng., 59(11) (1993)1827-1833.

[9] P. S. Nesterenko, A. A. Bondarev, A. R. Ingemansson, D. V. Krainev, Yu. L. Chigirinsky, Mathematical model of formation the axial component of the cutting forces at turning structural alloyed steel 3120 [Electronic resource], Modern scientific research and their practical application: research bulletin SWorld: [electron. journal], No. 6, vol. J11410 (Technical Sciences), (2014) 232-238.

[10] A. B. Kaplun, E. M. Morozov, ANSYS in the hands of an engineer: Practical guide, M. A. Shape. – M.: editorial URSS, 2003, 272 p.

[11] Świć, A., WoŁos, D., Zubrzycki, J., Opielak, M., Gola, A., & Taranenko, V. Accuracy control in the machining of low rigidity shafts (2014).

DOI: 10.4028/www.scientific.net/amm.613.357

[12] Birger, I. A. Residual stresses, M.: Mashgiz, 1963, 232 p.

[13] Gorshkov, A. G. Starovoitov, E. I. Tarlakovsky, D. V. Theory of elasticity and plasticity, M.: FIZMATLIT (2002)416 p.

[14] V. V. Guz, G. V. Muratkin, Installation for straightening shafts with simultaneous finishing and strengthening treatment, Patent of the Russian Federation No. 98964. (2010).

[15] O. I. Drachev, D. A. Rastorguev, A Device for turning, Patent RF №2532569. 2013. Bull. No. 14.

[16] A. Kobzev, L. K. Generals, Model of the process of turning the automatic control system, STIN, No. 11 (2008) 26-29.
