Strength Analysis of Single-Symmetry Ratio for Single-Symmetry I-Beam

Abstract:

Double-symmetry I-beams are the most common beam cross-sections in structural building. Because that is simpler to design and analyze steel profiles than single-symmetry I-beams. However, with the advancement of economy, the improvement of the quality of life and the cultural standards, large-scale emergence of various large span bridges, special bridge-type landscapes and viaducts. Single symmetrical I-section is better than Double-symmetry I-section to fairly in line with demand characteristics and material economy. This study chooses different I_yc/I_y ratio sections, 0.229, 0.23, 0.3 and 0.5. I_yc/I_y =0.23 is the change point of the sudden drop of the strength of the compressed airfoil. In study, the section is divided into three sections of plasticity, inelasticity and elasticity for analysis and comparison. Considering the different section sizes. If the value of L_b for a small non-elastic interval is too large, the section with a smaller cross-section will reach the elastic interval. Taking all section conditions L_b into consideration, taking 1.4m as a section will reach the non-elastic interval, if the value of the longer L_b is too small, the section with the larger section does not reach the elastic interval. In study, 10m is taken as the section to reach the elastic interval, orientation the AISC ( 2017 ) specification is used to analyze the I-beam. Symmetrical wing plate cross-sections were increased and reduced. The strength of the cross-sections between the compressed side and the tensioned side was discussed, and a single-symmetric I-section with the best cross-sectional efficiency was proposed.

• Periodical: Materials Science Forum (Volume 1047)
• Pages: 202-206
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.1047.202
• Online since: October 2021
• Authors: Wei Ting Hsu*, Kun Ze Ho, Yu Xin Liu, Shu Ti Chung
• Keywords: AISC (2017) Specification, Bending Moment Strength, Compression Flange, Double Symmetry I Beam, Lateral-Torsional Buckling (LTB), Single Symmetry I Beam, Single Symmetry Ratio ρ

References

[1] V.Z. Vlasov, Thin-walled elastic bars, Israel Program for Scientifc Translations, Jerusalem, (1961).

[2] D.A. Nethercot, in: The Effective Lengths of Cantilevers as Governed by Lateral Buckling, The Institution of Structural Engineers, Vol.51, NO.5, pp.161-168. (1973).

[3] A. Andradea, D. Camotim, P. Providência e Costa, in: On the evaluation of elastic critical moments in doubly and singly symmetric I-section cantilevers, Journal of Constructional Steel Research, Vol.63, No.7, pp.894-908. (2007).

DOI: 10.1016/j.jcsr.2006.08.015

[4] Taras, Andreas, Greiner, Richard, in: New design curves for lateral torsional buckling—Proposal based on a consistent derivation, Journal of Constructional Steel Research, Vol.66(5), pp.648-663. (2010).

DOI: 10.1016/j.jcsr.2010.01.011

[5] Jankowska-Sandberg, Joanna, Kołodziej, Jarosław, in: Experimental study of steel truss lateral–torsional buckling, Engineering Structures, Vol.46, pp.165-172. (2013).

DOI: 10.1016/j.engstruct.2012.07.033

[6] A.K. Dessouki, A.B. AbdelRahim, D.O. Abdul Hameed, in: Bending strength of singly-symmetric overhanging floor I-beams, HBRC Journal, HBRC, Vol.11, No.2, pp.176-193. (2014).

DOI: 10.1016/j.hbrcj.2014.03.003

[7] Kucukler, Merih, Gardner, Leroy, Macorini, Lorenzo, in: Lateral–torsional buckling assessment of steel beams through a stiffness reduction method, Journal of Constructional Steel Research, Vol.109, pp.87-100. (2015).

DOI: 10.1016/j.jcsr.2015.02.008

[8] B. Badari, F. Papp, in: On design method of lateral-torsional buckling of beams: State of the art and a new proposal for a general type design method, Periodica Polytechnica Civil Engineering, Vol.59(2), pp.179-192. (2015).

DOI: 10.3311/ppci.7837

[9] D. Dönmez Demir and E. Koca, in: Variational Iteration Method for Transverse Vibrations of the Elastic, Tensioned Beam, International Journal of Materials, Mechanics and Manufacturing vol. 5, no. 3, pp.187-190. (2017).

DOI: 10.18178/ijmmm.2017.5.3.315

[10] American Institute of Steel Construction : The AISC 2017 Steel Construction Manual, 15th Ed. and 2015 Specification Seminar(Trans Tech Publications, USA (2015).
