Graded Structure in SHS Ceramic-Lined Layered Pipes

Abstract:

Aiming at ceramic-lined layered pipes employed under special conditions, layered structure of ceramic-lined pipes is redesigned by adding (TiO2+Al+C+Ni) subsystem with different contents in (CrO3+Al) main system，and the composite pipe with three-layer structure of steel substrate, the intermediate and ceramics is obtained. SEM images and EPMA analyses indicate that the intermediate is made of Cr-Ni-Fe-Al-Ti, in which Ti carbide particles or fine dendrites of Ti enrichment are embedded with graded distribution. Mechanical tests and SEM images show that as (TiO2+Al+C) subsystem and Ni metallic additive is up to 10% and 15% of whole combustion system respectively, compressive strength and compressive shear strength of the pipe simultaneously reach the maximum values.

• Periodical: Materials Science Forum (Volumes 475-479)
• Pages: 1559-1562
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.475-479.1559
• Online since: January 2005
• Authors: Long Zhang, Zhong Min Zhao, Yu Zhong Yang, Bao Hong Han
• Keywords: Ceramic-Lined Layered Pipes, Combustion Synthesis (CS), Graded Structure, Transient Bonding

References

[1] S.G. Zhang, X.X. Zhou and D. H. Qian: Acta Metallurgica Sinica Vol. 35(1999), p.134.

[2] L. Zhang, Z.M. Zhao and J. J. Wang: Foundry Vol. 47(1998), p.4.

[3] G. cliché and S. Dallaire: Mater. Sci. Eng. Vol. 148(1991), p.319.

[4] O. Odawara and J. Ikeuchi: Transaction of the Japan Institute Materials Vol. 45(1981), p.316.

[5] D.Y. Zhu, Z.H. Jin, Y.L. Wang and H.Q. Hao: Transactions of The China Welding Institute Vol. 19(1998), p.94.

[6] T.W. Chou: Structure and Properties of Composites(VCH Publishers, Inc., U.S. A 1993).
