The Flow Characteristic Study of Gas Spray Process in Baosteel Spray Forming Equipment

Abstract:

The simulation software of compressible gas flow process in spray forming equipment was developed under three-dimensional cylindrical coordinates. When the gas flow strands sprayed from some definite angles into the atomizer chamber, they converged at the definite height in axial line then expanded outside which showed the jet current characteristic. The substrate stagnated the divergence jet strands of gas and then separated the flow strand into two big recycle zones in whole space. One of the recycle flow zone directed downwards, the other recycle flow zone, directed upwards and reached the inlet area, which is the main reason caused the bonding of small liquid drop in the delivery hole.

• Periodical: Materials Science Forum (Volumes 475-479)
• Pages: 2815-2818
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.475-479.2815
• Online since: January 2005
• Authors: Jun Fei Fan, Yin Zhang, San Bing Ren, You Duo He, Jing Guo Zhang, De Sheng Sun, Hai Rong Le
• Keywords: Droplets, Gas Flow, Movement, Spray Forming

References

[1] Mathur P, Applian D, Lawley A. Analysis of the spray deposition process [J] , Acta Metallurgy, 37(2). (1989).

[2] Lawrynowicz A., Liang X., Srivatsan T.S., et al. Processing, microstructure and fracture behavior of a spray-atomized and deposited nickel aluminide intermetallic, Journal of Materials Science 33(1998), p.1661.

[3] Gutierez E. Lavernia E.J., Grant N J., A mathematical model of spray deposition [J], Metall. Trans., 20Ａ(1), (1989), p.71.
