Producing a Random Recrystallization Texture in 6111 Aluminium Alloy

Cynthia S.T. Chang; A.S.C. Yeung; B.J. Duggan

doi:10.4028/www.scientific.net/MSF.495-497.591

Paper Titles

Friction Effects on Through-Thickness Texture Evolution during Rolling
p.567

Recrystallization Texture and r-Value of Rolled and T4-Treated Al-Mg-Si Alloy Sheets
p.573

Texture Formation during High Temperature Deformation of Al-3mass%Mg Solid Solution
p.579

Texture Segregation and Texture Change in the Biaxial Stretching of AA6016
p.585

Producing a Random Recrystallization Texture in 6111 Aluminium Alloy
p.591

Microstructure and Texture Control of Al-Mg Alloy Sheets by Differential Speed Rolling
p.597

Rolling and Recrystallization Textures in High Purity Al Cold Rolled to Very High Rolling Reductions
p.603

Uniformity of Grain Coarsening in Submicron Grained Al-Sc Alloy Containing Local Variations in Texture
p.609

AluMATTER, a New Interactive E-Learning Tool
p.615

HomeMaterials Science ForumMaterials Science Forum Vols. 495-497Producing a Random Recrystallization Texture in...

Producing a Random Recrystallization Texture in 6111 Aluminium Alloy

Abstract:

6111 Aluminium Alloy in the hot band state was cold rolled to 80% was then annealed at 450oC, 500oC and 540oC for recrystallization. The hot band was also solution heat treated, cold rolled and annealed to the same temperature to look at the difference in the recrystallization texture and precipitation states. It was found that the samples which were cold rolled and annealed without solution heat treatment gave Goss and P components after annealing. For the samples with solution heat treatment, the 450oC sample has a retained Cu type rolling texture while for the 500oC and 540oC the textures are quite random. The retained rolling texture found in the 450oC sample is due to the fact that it was partially recrystallized as the precipitates prevent complete recrystallization. The difference in the precipitation states during and after annealing of the samples with and without solution heat treatment affects the final recrystallization texture.
