Elliptic Gear Parametrical Design and Machining Simulation

Abstract:

The principle of generating conjugate tooth profile for elliptic gear was studied. On this basis, 3D modeling and parametrical design of elliptic gear were realized by using Solidworks API. The program provides a useful tool for further using finite element analysis to conduct strength analysis, numerical manufacture and computer aided simulation.
