Dynamic Responses of TiNi Phase Transformation Cylindrical Shell under Radial Impact Load

Abstract:

In this paper, radial impact responses of TiNi phase transformation cylindrical shell were experimentally studied on two-directional constraint. The nominal load-displacement curve was gained by advanced SHPB; meanwhile, the deformation process of the cylindrical shell was recorded by the high speed camera (30000 fps). The effect of stress wave on the whole structure during load process was as follows: the load-displacement curve fluctuated fiercely and rose gradually in the beginning period, whose frequency was basically the same as that of the stress wave propagation in the Striker 2; After that, the load-displacement curve tended to flat, the shell structure became to be ellipse as the compression increases, and the whole unload process slowed down. Finally, the surface strain was obtained by processing the shell deformation image, and the dynamic effect of the material phase transition and phase transition hinge on the cylindrical shell was examined.

You might also be interested in these eBooks

Advanced Material Science and Technology

View Preview

Info:

Periodical:

Materials Science Forum (Volumes 675-677)

Pages:

1155-1158

DOI:

https://doi.org/10.4028/www.scientific.net/MSF.675-677.1155

Citation:

Cite this paper

Online since:

February 2011

Authors:

Hui Jie Zhang, Zhi Ping Tang, He Huang

Keywords:

Phase Transformation Hinge, Radial Impact, Specific Energy, TiNi Cylindrical Shell

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] Gninga P B, Tarfaoui M: Damage development in thick composite tubes under impact loading and inﬂuence on implosion pressure: experimental observations. Composites Part B Engineering Vol. 36 (2005), pp.306-318.

DOI: 10.1016/j.compositesb.2004.11.004

Google Scholar

[2] Xu Weiwei: Numerical simulation study for the impact response of several basic phase transition structures. University of science and technology of China press, (2009), pp.131-160.

Google Scholar

[3] Zhang Huijie, Tang Zhiping, Li Dan: Experiment investigation on radial compression characteristics of cylindrical shell. Journal of Experimental Mechanics Vol. 24 (2009), pp.525-531.

Google Scholar

[4] TANG Zhiping: Shock phase transformation. ( Science Press , Beijing 2008, pp.174-180).

Google Scholar
