Influence of Nb Addition on Phase Transformation of TiNiFe Shape Memory Alloy

Abstract:

The influence of Nb addition on phase transformation, especially the intermediate R phase transformation and microstructure of TiNiFe shape memory alloys were investigated by means of electrical resistivity, optical microscope, energy dispersive spectroscopy and X-ray diffraction. The results showed that the R phase transformation was inhibited with the increase of Nb content. The martensite start transformation temperature decreased from 227K to 158K when the Nb content increased from 0.5 at.% to 2 at.%. The microstructure of the alloys were mainly characterized by TiNi matrix phase in which Fe and Nb resolved.

• Periodical: Materials Science Forum (Volume 687)
• Pages: 494-499
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.687.494
• Online since: June 2011
• Authors: Hang Man Lai, Fu Shun Liu
• Keywords: Martensite Transformation, R-Phase Transformation, TiNiFeNb Shape Memory Alloys

References

[1] Otsuka K, Ren X. Recent developments in the research of shape memory alloys. Intermetallics 1999; 7(5): 511-528.

DOI: 10.1016/s0966-9795(98)00070-3

[2] Yang G J, Hao S M. Influence of Alloy Composition on the Phase Transformation and Shape Memory Effect of TiNiNb Alloys. Rare metal Materials and Engineering 1996: 25(5): 30-33.

[3] Li Z Y, Liu F S, Xu H B. Influence of Fe Addition on Phase Transformation Temperatures and Mechanical Properties of TiNi Shape Memory Alloys. Acta Aeronautica et Astronautica Sinica 2004; 25(1): 84-87.

[4] Wang J G, Liu F S. Phase Transformation and Microstructure of Ti50Ni48-xFe2Ndx Shape Memory Alloys. Chinese Journal of Aeronautics 22(2009): 334-338.

DOI: 10.1016/s1000-9361(08)60107-7

[5] Xiao L, Liu F S, Xu H B. Effect of Al addition on properties of TiNiFe shape memory alloys. Transactions of Nonferrous Metals Society of China 16(2006): s100-s103.

[6] Zheng Y F, Jiang F, Li L, Yang H, Liu Y N. Effect of ageing treatment on the transformation behaviour of Ti-50. 9 at. % Ni alloy. Acta Materialia 56(2008): 736-745.

DOI: 10.1016/j.actamat.2007.10.020

[7] Otsuka K, C.M. Wayman. Shape Memory Materials. Cambridge University Press, London: (1998).

[8] Zhao X Q, Yan X M, Yang Y Z, Xu H B. Wide hysteresis NiTi(Nb) shape memory alloys with low Nb content(4. 5 at. %). Materials Science and Enginering A 438-440(2006): 575-578.

DOI: 10.1016/j.msea.2006.03.110

[9] J. I. Kim, Yinong Liu, S. Miyazaki. Ageing-induced two-stage R-phase transformation in Ti-50. 9at. % Ni. Acta Materialia 52(2004): 487-499.

DOI: 10.1016/j.actamat.2003.09.032

[10] P. Sittner, M. Landa, P. Lukas, V. Novak. R-phase transformation phenomena in thermomechanically loaded NiTi polycrystals. Mechanics of Materials 38(2006): 475-492.

DOI: 10.1016/j.mechmat.2005.05.025

[11] He X M, Zhao L Z, Duo S W, Zhang R F, Rong L J. Stress-induced martensitic transformation in (Ni47Ti44)100-xNbx shape memory alloys with wide hystersis. Trans. Nonferrous Met. Soc. China 16(2006) : s42-s46.

DOI: 10.1016/s1003-6326(06)60139-8

[12] X. M. He, L. J. Rong, D. S. Yan, Y. Y. Li. TiNiNb wide hystersis shape memory alloy with low niobium content. Materials Science and Engineering A 371(2004): 193-197.

DOI: 10.1016/j.msea.2003.11.044
