Study on Welding of TIG Tailor Welded Galvanized Sheets and Formability of Stretch Forming

Abstract:

In this study TIG welding of Tailor welded Galvanized Sheets and their formability of stretch forming have been carried out. It has been found that the microstructure of weld region is ferrites and pearlites, and the microstructure of heat-affected zone (HAZ) is blocky pearlites and ferrites. Stretch tests suggested that when the weld line parallels the tensile axis, σs , σb and the σs/σb is higher than that of the weld line perpendicular to the tensile axis. When the weld line parallels the tensile axis, the elongation of the specimen and n are lower than that of the specimen with the weld line perpendicular to the tensile axis. When the weld line perpendicular to the tensile axis, the fracture surface is basically the same as that of the base metal, when the weld line parallels the tensile axis, the fracture surface is dimples and cleavages.

• Periodical: Materials Science Forum (Volumes 704-705)
• Pages: 1512-1518
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.704-705.1512
• Online since: December 2011
• Authors: Yun Tao Li, Wen Jun Zhang, Xu Ma, Guang Da Liu, Li Jun Yang
• Keywords: Microstructure, Stretch Formability, Tailor Welded-Galvanized Sheets, TIG Welding

References

[1] Fu Hanguang, Wu Jianzhong. Automotive galvanized plate development and the status quo [J]. Research of Iron and Steel, 1998 (6): 57.

[2] Bian Jun, et al. production and prospects of Chinese hot galvanized steel sheet [J]. Research of Iron and Steel, 2002 (6): 57～59.

[3] Li Xia. Analysis of WDB Steel [J]. Water Conservancy and Electric Power Machinery, 2007, 29 (8): 56 ~ 57.

[4] T. Senthil Kumar a, V. Balasubramanian b, M.Y. Sanavullah. Influences of pulsed current tungsten inert gas welding parameters on the tensile properties of AA 6061 aluminum alloy Materials and Design . 2007 (28): 2080～(2092).

DOI: 10.1016/j.matdes.2006.05.027

[5] Yuliang Shi, Zhongqin Lin, Ping Zhu, Shanling Han. Impact modeling of the weld line of tailor-welded blank [J]. Materials and Design 2008(29): 232～238.

DOI: 10.1016/j.matdes.2006.12.005

[6] Sushanta Kumar Panda a, D. Ravi Kumara, Harish Kumarb, A.K. Nath b. Characterization of tensile properties of tailor welded IFsteel sheets and their formability in stretch forming[J]. Journal of Materials Processing Technology , 2007(183) : 321～332.

DOI: 10.1016/j.jmatprotec.2006.10.035

[7] Zhang Wenyue. Welding metallurgy [M]. Beijing: Mechanical Industry Press, 2005, 10: 227.

[8] Guo Liwei, Sun Dayong，Gufeng et al. The two plate welding process and joint properties of plastic deformation of Different thickness plate[J]. Harbin University of Science and Technology, 2003, 8 (2) : 12～15.
