Application of Sintered Steel for Synchronizer Rings Used in Mechanical Transmissions

Abstract:

Synchronizer rings are mechanical components that equalize the gear rotation to be engaged with the sliding sleeve. It is done by the friction property of the synchronizer ring material. Different types of materials are used to manufacture synchronizer rings depending on the application. There are basically two groups of material: dual function, structural and friction properties (Cu-Zn alloys, Al-Si alloys, etc.) and single function, only structural property (rolled and sintered steels, Cu-Zn alloys, Al alloys, etc.). The objective of this work was to propose a solution to the synchronizer ring structural material of a new mechanical transmission design. This component was initially designed with a Cu-Zn alloy and showed premature failure on synchronizer teeth during tests. To eliminate this problem several technical alternatives were analyzed considering the best cost and benefits ratio, defining to use the sintered steel FLC-4908 per MPIF Standard 35.

• Periodical: Materials Science Forum (Volumes 727-728)
• Pages: 349-355
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.727-728.349
• Online since: August 2012
• Authors: T.F. Andrade, A.C. Zambon, C.H.C. Sena, A.G. Bida, J.R. Kavai
• Keywords: Brass, Mechanical Transmission, Plastic Deformation, Sinter-Hardening, Synchronizer Ring, Weibull Distribution

References

[1] A. Bouffet. Evaluating tribology of synchronizers for today's manual transmissions. Toulouse: SAE. SAE paper 2004-01-2022. 8 p. (2004).

DOI: 10.4271/2004-01-2022

[2] G. Lechner, H. Naunheimer. Automotive transmissions: fundamentals, selection, design and application. Berlin: Springer 448 p. (1999).

[3] L. Mccord. Gylon friction material for transmission synchronizers. Detroit: SAE. SAE paper 860382. 8 p. (1986).

DOI: 10.4271/860382

[4] L.S. Sigl et al. Processing and performance of PM synchronizer rings with friction linings. Valência: [s. n. ] (2003).

[5] J.W.K. Chan and T.K.L. Tong: Mater Des. Vol. 28 (2007), p.1539.

[6] M. Rajab and D.S. Coleman: Powder Metall Vol. 28 (4) (1985), p.207.

[7] Minitab 16 Statistical Software (2011). [Computer software]. Eaton Corporation: Minitab, Inc. (http: /www. minitab. com).

[8] W. Weibull. A Statistical Representation Of Fatigue Failures In Solids, Transactions Of The Royal Institute Of Technology, Stockholm, Sweden, Number 27 (1949).

[9] W. Weibull. A Statistical Distribution Function of Wide Applicability, ASME Journal of Applied Mechanics, Transactions of the American Society of Mechanical Engineers, September (1951).

[10] R. Ratzi and P. Orth: Metal Powder Report Vol. 55 (7-8) (2000), p.20.

[11] H Mindivan, H. Çimenglu, E.S. Kayali: Wear Vol. 254 (2003), p.532.

[12] W. Nelson: Journal of Quality Technology Vol. 17 (3) (1985).
