Service Life Extension of Stainless Steel Wire Mesh Belts for Sintering Furnaces

Abstract:

The service life of stainless steel wire mesh belts in sintering furnaces is limited, because material deterioration results in wire fracture. A newly developed humidification system establishes a furnace atmosphere that maintains a protective oxide scale on the belt surface throughout the sintering process and at the same time creates an environment that is reducing to the sintered metal compact. This work includes thermodynamic calculations of the furnace atmosphere dew points that satisfy these oxidation / reduction criteria. Scanning Electron Microscopy, combined with Energy-dispersive X-ray Analysis, and mechanical testing methods have been used to compare belts that have undergone the same length of service in a nitrogen-hydrogen atmosphere and in an atmosphere that was modified using the newly developed humidification method. The material examinations have revealed that the new humidification system significantly extends the service life of stainless steel belts.

• Periodical: Materials Science Forum (Volumes 727-728)
• Pages: 412-423
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.727-728.412
• Online since: August 2012
• Authors: Anna Wehr-Aukland, Donald J. Bowe, Anthony M. Zaffuto, Jeremy Gabler, Gian Ricardo C. Silva

References

[1] G.D. Smith and R.A. Smith, Characteristics of Current and Advanced Wire Mesh Belt Alloys for Sintering Furnaces, Industrial Heating, October 1995, pp.61-63.

[2] G.D. Smith, H.L. Flower and R.D. Riva, Alloy Selection Criteria for High Temperature Sintering Belts, Advances in Powder Metallurgy & Particulate Materials, compiled by C.L. Rose and M.H. Thibodeau, Metal Powder Industries Federation, Princeton, NJ, 1999, part 3, pp.17-28.

[3] M.F. Coyle and R.D. Riva, Finite Element Analyses of Wire Mesh Furnace Belts, Advances in Powder Metallurgy & Particulate Materials, compiled by H. Ferguson and D.T. Whychell, Metal Powder Industries Federation, Princeton, NJ, 1999, part 1, pp.83-93.

DOI: 10.1016/s0026-0657(01)80539-7

[4] J.G. Marsden, D.J. Bowe, K.R. Berger and D. Garg, D.L. Mitchell, Atmospheres for Extending Life of Belts within Sintering Furnaces, U.S. Patent No. 5, 613, 185, March 18, (1997).

[5] Passport to Steel powered by CASTI, ASTM International, http: /www. casti. ca/database.

[6] H. J. Grabke, Carburization – A High Temperature Corrosion Phenomenon, MTI publication no. 52, 1998, Material Technology Institute of the Chemical Process Industries, St. Louis, MO.

[7] G. Y. Lai, High Temperature Corrosion and Materials Applications, 2007, ASM International, Materials Park, OH.

[8] S. R. Pillai, High Temperature Corrosion of Austenitic Stainless Steels", Corrosion of Austenitic Stainless Steels: Mechanism, Mitigation and Monitoring, edited by H.S. Khatak and B. Raj, Woodhead Pub., Cambridge, UK, Alpha Science, Pangbourne, UK, 2002, pp.265-286.

DOI: 10.1533/9780857094018.287

[9] ASTM A370-10, Standard Test Methods and Definitions for Mechanical Testing of Steel Products.

[10] ASTM E8-09, Standard Test Methods for Tension Testing of Metallic Materials.

[11] R.H. Shay, T.L. Ellison and K.R. Berger, Control of Nitrogen Absorption and Surface Oxidation of Austenitic Stainless Steels in H2-N2 Atmospheres, 1983, Air Products Technical Data, Air Products and Chemicals, Inc., Allentown, PA.

[12] FactSage™ thermochemical software and database package developed jointly between Thermfact/CRCT (Montreal, Canada) and GTT-Technologies (Aachen, Germany), version 6. 2, (2010).
