Extensions of Electron Diffraction Based Techniques in Crystallographic Characterization

Abstract:

Abstract. With the advance of electron diffraction techniques in individual orientation analysis, traditional crystallographic characterization methods could be simplified, thus offering chances to develop some new approaches. In recent years, our group has devoted to working on possible extensions of the SEM and TEM based techniques for crystallographic analyses on a microstructure- and orientation-specific level. Several methods are illustrated in this paper, including the determination of dislocation type and Burgers vector without recourse to the traditional g.b invisibility condition, the identification of twinning mode and complete twinning elements for any crystal symmetry that requires minimum initial data input, and the characterization of specific interface plane or slip plane using only one sample observation plane instead of two perpendicular sample planes. These new extensions of characterization methods have proven to facilitate the related microstructural examinations.

• Periodical: Materials Science Forum (Volume 753)
• Pages: 11-16
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.753.11
• Online since: March 2013
• Authors: Liang Zuo, Zong Bin Li, Yu Dong Zhang, Claude Esling, Xiang Zhao
• Keywords: Burgers Vector, Crystallographic Orientation, Dislocation, Electron Diffraction, Interface, Twin

References

[1] A. Morawiec, J. Appl. Cryst. 32 (1999) 788-798.

[2] A. Morawiec, J.J. Fundenberger, E. Bouzy, J. Lecomte, J. Appl. Cryst. 35 (2002) 287.

[3] R.A. Schwarzer, Ultramicroscopy 67 (1997) 19-24.

[4] J. Portillo, E.F. Rauch, S. Nicolopoulos, M. Gemmi, D. Bultreys, Mater. Sci. Forum 644 (2010) 1-7.

[5] V. Randle, J. Microscopy 230 (2007) 406-413.

[6] V. Randle, Scripta Mater. 44 (2001) 2789-2794.

[7] Y.D. Zhang, S.Y. Wang, C. Esling, J.S. Lecomte, C. Schuman, X. Zhao, L. Zuo: J. Appl. Cryst. 44 (2011) 1164-1168.

[8] Y.D. Zhang, Z.B. Li, C. Esling, J. Muller, X. Zhao, L. Zuo: J. Appl. Cryst. 44 (2010) 1426-1430.

[9] Y.D. Zhang, C. Esling, X. Zhao, L. Zuo: J. Appl. Cryst. 40 (2007) 436-440.

[10] J.W. Edington: Interpretation of Transmission Electron Micrographs, Monographs in Practical Electron Microscopy in Materials Science, Macmillan, London, 1975.

[11] H.J. Bunge, C. Esling, J. Muller: Acta Cryst. A 37 (1981) 889-899.

[12] B.A. Bilby, A.G. Crocker: Proc. R. Soc. London Ser. A 288 (1965) 240-255.

[13] Z.B. Li, Y.D. Zhang, C. Esling, X. Zhao, L. Zuo: Acta Mater. 59 (2011) 3390-3397.

[14] C.S. Barrett: Structure of Metals, 2nd ed., MacGraw-Hill, New York, 1952.
