Advanced Nano-Finishing Process of SrTiO₃ Substrate by Cluster MR-Effect Plate

Abstract:

As a new multifunctional material, strontium titanate (SrTiO3) ceramic has a wide application in grain boundary layer capacitor (GBLC) with the microstructure characteristics of semi-conductive crystalline grain and insulated boundary. An ultra-precision nanofishing technique is developed to lap and polish the brittle and thin SrTiO3 substrate with the cluster MR-effect plate where the abrasives are constrained by the cluster MR-effect chains, under the influence of a magnetic field, the carbonyl iron particles (CIPs) and non-magnetic abrasive particles remove material from the surface of workpiece being machined in this paper. Mahr XT20 roughmeter, Keyence VHX-600 and Olympus S4000 microscopes are used to investigate the characteristic of machined surface and the mechanism of material removal. An ultra-smooth planarization surface of SrTiO3 substrate with surface roughness Ra 3.8 nm (Mahr), RMS 0.973 nm (Veeco interferometer) is obtained under a high efficiency. It is found that the pore structures of the sintered substrate would weak the machinability of SrTiO3 and influence the further improvement of surface quality.

• Periodical: Materials Science Forum (Volume 770)
• Pages: 150-154
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.770.150
• Online since: October 2013
• Authors: Zhen Wei Bai, Qiu Sheng Yan, Jia Bin Lu
• Keywords: Cluster MR-Effect, Nanofinishing, SrTiO₃ Substrate, Viscoplastic Polishing Pad

References

[1] S.C. Zhang, B.C. Chen, Y.X. Han: MINING & MRTALLURGY. Vol. 3 (2001), p.63.

[2] S. Jin, Y. Jing, T.Y. Qi, etal: JOURNALOF SALTLAKE RESEARCH. Vol. 3 (2004), p.55.

[3] J.F. Yang, Y.L. Feng, H.F. Zhao, etal: MATERIALS RESEARCH AND APPLICATION. Vol. 3(2008), p.207.

[4] Feltz: Int. Society for Optical Engineering 7088, 706006 (2008).

[5] Z.C. Wu, Q.S. Yan: Key Engineering Materials. Vol. 487(2011), p.283.

[6] Z.W. Bai, Q.S. Yan: Diamond＆Abrasives Engineering. Vol. 5(2011), p.35.

[7] G.Z. Chen, Y. Hang: JOURNAL OF SYNTHETIC CRYSTALS. Vol. 5(2008), p.1107.

[8] Q.S. Yan, J.W. Yan, J.B. Lu, et al: Advanced Materials Rsearch. Vol. 135(2010), p.18.

[9] J.F. Chai, Q.S. Yan, P.C. Zhang: China Mechanical Engineering. Vol. 11(2010), p.2726.

[10] A. Sidpara, V K. Jain: J. of Machine Tools and Manufacture Vol. 51(2011), p.358.

[11] J.S. Pan, Q.S. Yan: Physics Procedia Vol. 25(2012), p.176.
