Multiple-Section Process Information Description Method for 3D Instruction Publishing

Abstract:

To deal with the complete description and quick search for 3D process instruction publishing, a three-section process information description method was presented based on the features of process data. First, a three-section description model for 3D process instruction publishing is established according to the application type and data structure. Subsequently, an abstract matrix representation method is provided to express 3D process information, then the specific contents of the abstract matrix is analyzed and an instantiated matrix is given. Finally, an illustrative example is used to explain an application of the proposed approach.

• Periodical: Materials Science Forum (Volume 770)
• Pages: 316-319
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.770.316
• Online since: October 2013
• Authors: Dong Ping Zhao, Xi Tian Tian, Jun Hao Geng, Jian Jun Tang
• Keywords: 3D Process Information, Abstract Matrix, Instruction Publishing, Three-Section Description

References

[1] S.P. Lv, L.H. Qiao, J. Zhang: Computer Integrated Manufacturing Systems Vol. 16 (2010), p.2577.

[2] L. Gao, L.H. Qiao : ACTA Aeronautica et Astronautica Sinica Vol. 9 (2008), p.1068.

[3] L.H. Qiao, J. Zhang: Key Engineering Materials Vol. 407-408 (2009), p.298.

[4] Rajugan R, Change, Dillonts, et al: Lecture Notes in Computer Science Vol. 3716 (2005), p.79.

[5] Y. Zhao, R. Mo, Z.Y. Chang: Computer Integrated Manufacturing Systems Vol. 14 (2008), p.1106.

[6] S. Chen, C.T. Cai: Journal of Shanghai jiaotong university Vol. 43 (2009), p.944.

[7] C. T . Cai: Computer Integrated Manufacturing Systems Vol. 14 (2008), p.912.

[8] L. Li, Y.P. Hao, Q.L. Shu, etal: Engineering Science Vol. 5 (2003), p.75.
