Compression Property of C/SiC and Inconel X-750 Springs from Room Temperature to 1000°C

Abstract:

The compression properties of C/SiC composite and Inconel X-750 helical springs were investigated from room temperature (RT) to 1000°C in air. The density of C/SiC spring is 1.74 g/cm³, only ~1/5 of X-750 value (8.17 g/cm³) and the spring constants of C/SiC and X-750 springs at RT are 3.47 and 5.61 N/mm, respectively. The spring constants of X-750 spring decreased with increase of temperature. X-750 spring could keep excellent property below 600°C, but its spring constant was only 36.7% of RT value at 800°C and permanent deformation appeared. At 1000°C, it could not restore and was destroyed. The spring constants of C/SiC spring at 400°C and 600°C were appreciably higher than the RT value, and then decreased with temperature elevating. Above 800°C, the spring constant decreased with test progressing because of the oxidation of carbon fibers and SiC matrix. But it has a spring constant of 2.40 N/mm (69.2% of the RT value) at 1000°C and can revert to its original dimensions.

• Periodical: Materials Science Forum (Volume 789)
• Pages: 616-621
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.789.616
• Online since: April 2014
• Authors: Si’an Chen*, Yu Di Zhang, Chang Rui Zhang, Xin Xiong, Hai Feng Hu
• Keywords: C/SiC Composite, Compression Property, High-Temperature, Inconel X-750, Spring

References

[1] Steinetz B.M, Evaluation of an innovative high temperature ceramic wafer seal for hypersonic engine applications, NASA/TM-1992-105556, NASA, Washington, 1992.

[2] J. Feng, C. Zhang, J. Feng, Y. Jiang, N. Zhao, Carbon aerogel composites prepared by ambient drying and using oxidized polyacrylonitrile fibers as reinforcements, Appl. Mater. Interfaces 3 (2011) 4796-4803.

DOI: 10.1021/am201287a

[3] Jeffrey J. DeMange, Patrick H. Dunlap, Bruce M. Steinetz, An evaluation of high temperature airframe seals for advanced hypersonic vehicles, AIAA-2007-5743, AIAA, Cincinnati, 2007.

DOI: 10.2514/6.2007-5743

[4] A. Thomas, M. El-Wahabi, J. M. Cabrera, J. M. Prado, High temperature deformation of Inconel 718, J. Mater. Process. Technol. 177 (2006) 469-472.

DOI: 10.1016/j.jmatprotec.2006.04.072

[5] Y. Nishi, N. Uchiba, A. Kimura, A. Mizutani, Effects of EB irradiation on spring constant of C/C composite coil, J. Mater. Sci. 38 (2003) 2215-2218.

[6] J. K. Wright, R. M. Thomson, J. R. G. Evans, On the fabrication of ceramics windings, J. Mater. Sci. 25[1] (1990) 149-156.

[7] C. Kaya, E. G. Butler, Zirconia-toughened alumina ceramics of helical spring shape with improved properties from extruded sol-derived pastes, Scr. Mater. 48[4] (2003) 359-364.

DOI: 10.1016/s1359-6462(02)00460-8

[8] Israel Krindges, Raquel Andreola, Cla´udio A Perottoni, Janete E. Zorzi, Low-pressure injection molding of ceramic springs, Int. J. Appl. Ceram. Technol. 5[3] (2008) 243-248.

DOI: 10.1111/j.1744-7402.2008.02226.x

[9] Walter K, Chapter 6, 7, and 14, In Ceramic Matrix Composites: Fiber Reinforced Ceramics and their Applications, Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim, Germany, 2008.

DOI: 10.1080/10426910802612437

[10] Y. Ma, S. Wang, Z. Chen, Effects of high-temperature annealing on the microstructures and mechanical properties of C(f)/SiC composites using polycarbosilane, Mater. Sci. Eng. A-Struct. Mater. 528[7-8] (2011) 3069-3072.

DOI: 10.1016/j.msea.2010.12.095

[11] T. Hamilton, M. Gopal, E. Atchley, J. E. Smith, Experimental investigation on the mechanical performance of helical ceramic spring, J. Mater. Sci. 38[15] (2003) 3331-3335.

[12] S. Nohut, G.A. Schneider, Failure probability of ceramic coil springs, J. Eur. Ceram. Soc. 29 (2009) 1013-1019.

DOI: 10.1016/j.jeurceramsoc.2008.08.012

[13] S. Sato, K. Taguchi, R. Adachi, M. Nakatani, A study on strength characteristics of Si3N4 springs, Fatigue Fract. Engng. Mater. Struct. 19[5] (1996) 529-537.

DOI: 10.1111/j.1460-2695.1996.tb00989.x

[14] S. Chen, Y. Zhang, C. Zhang, X. Xiong, G. Li, H. Hu, A Simple Way to Prepare C/SiC Spring, Int. J. Appl. Ceram. Technol. 1 (2013)1-7.

[15] C. Zhou, C. Zhang, H. Hu, Y. Zhang, Z. Wang, Preparation of 3D-Cf/SiC composites at low temperatures, Mater. Sci. Eng. A-Struct. Mater. 488 (2008) 569-572.
