Porosity and Delamination Defect Detection in Ceramic Materials by Active Infrared Thermography and Optical Digital Microscopy

Abstract:

This paper examines the use of active lock-in thermography and optical microscopy coupled with digital image processing as a production-time quality control tool for porcelain tile manufacturing. We demonstrate that it is possible to associate physical properties such as density, porosity and water absorption capacity with internal defects such as thermal delamination in ceramics. Defective and intact samples were subjected to active lock-in thermography and digital microscopy analysis on a workbench developed to simulate the conditions found in production lines. The images were collected and processed using morphological operators, image enhancement and thresholding to detect the presence of defects. These methods were compared with methods that analyze the physical properties of the materials to demonstrate that it is possible to detect the presence of defects.

• Periodical: Materials Science Forum (Volumes 798-799)
• Pages: 671-676
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.798-799.671
• Online since: June 2014
• Authors: Claudinei Rezende Calado*, F.A.R. Calado, G. Caput, S.C. Gomes, R.M. Andrade
• Keywords: Active Thermography, Defect Detection, Line Quality Control, Optical Microscopy

References

[1] P. Castellini, E. Esposito, N. Paone, and E. P. Tomasini, Non-invasive measurements of damage of frescoes paintings and icon by Laser Scanning Vibrometer: experimental results on artificial samples and real works of art , Proc. of the 3rd International Conference on Vibration Measurements by Laser Techniques: Advances and Applications. 3411 (1998).

DOI: 10.1016/s0263-2241(00)00005-1

[2] E. Erena, S. Kurama, I. Solodov Characterization of porosity and defect imaging in ceramic tile using ultrasonic inspections. Ceramics International 38 (2012) 2145–2151.

DOI: 10.1016/j.ceramint.2011.10.056

[3] M. Romagnoli, M. Burani, G. Tari, J.M.F. Ferreira, A non-destructive method to assess delamination of ceramic tiles, Journal of the European Ceramic Society 27 (2007) 1631–1636.

DOI: 10.1016/j.jeurceramsoc.2006.05.069

[4] R. M. De Andrade, E. Esposito, N. Paone, G. M. Revel, Non-destructive Techniques for Detection of Delamination in Ceramic Tiles: a Laboratory Comparison between IR Thermal Cameras and Laser Doppler Vibrometers, Proceedings SPIE. 3585 (1999).

DOI: 10.1117/12.339868

[5] R. M. Andrade, A. Eduardo, Methodology for Automatic Process of the Fired Ceramic Tile's Internal Defect Using Infrared Images and ANN, Journal of Brazilian Society of Mechanical Science & Egineering. 33 (2011).

DOI: 10.1590/s1678-58782011000100010

[6] J. Rosso, E. S. Cunha, R. A. Rojas-Ramirez, Características técnicas e polimento de porcelanatos, Cerâmica Industrial. 10(4) (2005) 11-14.

[7] S. N. Aqida, M. I. Ghazali & J. Hashim, Effects of porosity on mechanical properties of metal matrix composite: an overview, Jurnal Teknologi. 40 (2004) 17-32.

DOI: 10.11113/jt.v40.395
