The Impact of Hardened Steel Milling Surface Structure on Mould Service Load

Abstract:

Mould surface loading state is one of the most important factors which would affect the mould performance in the course of service. According to the established hardened steel milling surface geometry model, a bending forming numerical simulation of hardened steel milling is conducted, the influence law of service process surface load state is analyzed under machined surface geometry structure which is formed by different milling parameters. The research results show: surface load concentrated area is mainly focusing on mould edge transition and fillet in the course of service; the surface geometry structure has an important influence on the mould service load in the course of service, service load more smaller which is more helpful to improve the mould service performance in the course of service.

• Periodical: Materials Science Forum (Volumes 800-801)
• Pages: 342-347
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.800-801.342
• Online since: July 2014
• Authors: Min Li Zheng*, Jin Hui Xu, Wei Zhang, Zhao Xing Zhang, Tong Wu
• Keywords: Hardened Steel, Milling Surface Structure, Numerical Simulation, Service Load

References

[1] W. J Xing. Research on impact-wearing behavior of quenched W6Mo5Cr4V2 for cold die [J]. JOURNAL OF HEFEI UNIVERSITY OF TECH NOLOGY. Vol. 33(2010), pp.1609-1611.

[2] C. C, L. F, A. P, F.M. Damage and fracture study of cold extrusion dies [J]. Engineering Fracture Mechanics. Vol. 71(2004), pp.1021-1033.

DOI: 10.1016/s0013-7944(03)00154-1

[3] P M. P, W M. The effect of the die radius profile accuracy on wear in sheet metal stamping [J]. International Journal of Machine Tools&Manufacture. (2013), pp.44-53.

DOI: 10.1016/j.ijmachtools.2012.11.001

[4] P M. P, W. Y Yan, R B.F. Sliding distance，contact pressure and wear in sheet metal stamping [J]. Wear. Vol. 268(2010), pp.1275-1284.

DOI: 10.1016/j.wear.2010.01.020

[5] C. H Li, X. C Wu, etc. Investigation on Wear Resistance of Cr8 Tool Steels [J]. Tribology. Vol. 3(2013), pp.36-43.

[6] V. R, L. M, V. T K. Surface deformation of steels in impact-abrasion: The effect of sample angle and test duration [J]. Wear. Vol. 301(2013), pp.94-101.

DOI: 10.1016/j.wear.2013.01.006

[7] S. L, Y. Q, C.L. Model for the prediction of 3D surface topography in 5-axis milling [J]. Int J Adv Manuf Technol. Vol. 51(2010), pp.915-924.

DOI: 10.1007/s00170-010-2686-3

[8] Y. Q, L. S, C.L. Surface topography in ball end milling process: Description of a 3D surface roughness parameter [J]. Journal of materials processing technology. Vol. 195(2008), pp.135-143.

DOI: 10.1016/j.jmatprotec.2007.04.129

[9] W Li, C. Y Wang, Z. C Tian, etc. Research on localized wear of the die based on contact stress analysis on die surface in stamping process [J]. JOURNAL OF PLASTICITY ENGINEERING. Vol. 20(2013), pp.33-37.
