Preparation and Mechanical and Optical Properties of SF/Pyrrolidone Blend Film

Abstract:

To improve the properties of silk fibroin film, the silk fibroin/pyrrolidone blend films were prepared by mixing silk fibroin and pyrrolidone solution at different ratios. The structure and mechanical properties of blend films were characterized. X-ray diffraction was used to investigate structure of the SF/PYR films, and the results indicated that the blend films were composed of the β-sheet form. Tensile strength and elongation at break of blend films were measured using an instron tensile tester. The results showed that tensile strength and elongation at break of blend films were high enough for application. Furthermore, the films’ flexibility was significantly improved. The optical clarity of blend film was tested by Microplate system. It can be seen from the results that optical clarity is not stable, but in some particular ratios we also can get high light transmittance blend films. At last, biocompatibility of blend films (the rate of the blend film is 30%) was accessed with L929 cell. The results showed that all types of blend films were able to support cell adhesion and proliferation. In addition, the cellular morphology of the cells cultured on blend films was better than that on silk fibroin films. In view of the mechanical properties and optical clarity, combined with their ability to support L929 proliferation suggests that this blend films will offer new options in many different biomedical applications.

You might also be interested in these eBooks

View Preview

Info:

Periodical:

Materials Science Forum (Volume 815)

Pages:

327-331

DOI:

https://doi.org/10.4028/www.scientific.net/MSF.815.327

Citation:

Cite this paper

Online since:

March 2015

Authors:

Jiao Jiao Li, Shan Shan Zhang, Xin Yue Zhang, Shen Zhou Lu*

Keywords:

Biocompatibility, Blend Film, Property, Silk Fibroin

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] P. Aiken-O'Neill, J. Mark and M.D. Mannis, Summary of Corneal Transplant Activity: Eye Bank Association of America, Cornea. 21 (2002)1-3.

DOI: 10.1097/00003226-200201000-00001

Google Scholar

[2] K. Nishida,M. Yamato and Y. Hayashida, Corneal Reconstruction with Tissue-Engineered Cell Sheets Composed of Autologous Oral Mucosal Epithelium, NEJM. 12 (2004)1187-1196.

DOI: 10.1056/nejmoa040455

Google Scholar

[3] A.J.T. George and D.F.P. Larkin, Corneal Transplantation: The Forgotten Graft, American Journal of Transplantation. 4 (2004)678-685.

DOI: 10.1111/j.1600-6143.2004.00417.x

Google Scholar

[4] D. Myung,W. Koh,A. Bakri,M. Amanda,K. Jungmin,N. Jaan,C. Michael R.C. Jennifer W.F. Curtisand N.T. Christopher, Design and fabrication of an artificial cornea based on a photolithographically patterned hydrogel construct, Biomedical microdevices. 9 (2007).

DOI: 10.1007/s10544-006-9040-4

Google Scholar

[5] O. Ilhan-Sarac and E.K. Akpek, Current concepts and techniques in keratoprosthesis, Current opinion in ophthalmology. 16 (2005)246-250.

DOI: 10.1097/01.icu.0000172829.33770.d3

Google Scholar

[6] H.J. Jin,J. Park,V. Karageorgiou U.J. Kim,R. Valluzzi,P. Cebe and D.L. Kaplan, Water-Stable Silk Films with Reduced β-Sheet Content, Advanced Functional Materials. 15 (2005)1241-1247.

DOI: 10.1002/adfm.200400405

Google Scholar

[7] A. Motta,L. Fambri and C. Migliaresi, Regenerated silk fibroin films: thermal and dynamic mechanical analysis, Macromolecular Chemistry and Physics. 203 (2002)1658-1665.

DOI: 10.1002/1521-3935(200207)203:10/11<1658::aid-macp1658>3.0.co;2-3

Google Scholar

[8] Z. Shao and F. Vollrath, Surprising strength of silkworm silk, Nature. 418 (2002)741.

DOI: 10.1038/418741a

Google Scholar

[9] C. Vepari D.L. Kaplan, Silk as a biomaterial, Progress in polymer science. 32(2007)991-1007.

DOI: 10.1016/j.progpolymsci.2007.05.013

Google Scholar

[10] B. Panilaitis G.H. Altman,J. Chen H.J. Jin,V. Karageorgiou and D.L. Kaplan, Macrophage responses to silk, Biomaterials . 24(2003)3079-3085.

DOI: 10.1016/s0142-9612(03)00158-3

Google Scholar

[11] L. Meinel,S. Hofmann,V. Karageorgiou C.K. Head,J. McCool,G. Gronowicz,L. Zichner and R. Langer, The inflammatory responses to silk films in vitro and in vivo, Biomaterials . 26(2005)147-155.

DOI: 10.1016/j.biomaterials.2004.02.047

Google Scholar

[12] H.J. Jin,J. Park,V. Karageorgiou U.J. Kim,R. Valluzzi,P. Cebeand D.L. Kaplan, Water-stable silk films with reduced beta-sheet content, Advanced Functional Materials. 15 (2005)1241-1247.

DOI: 10.1002/adfm.200400405

Google Scholar

[13] T. Arai,G. Freddi,R. Innocenti and M. Tsukada, Biodegradation of Bombyx mori silk fibroin fibers and films, Journal of Applied Polymer Science. 91(2004)2383-2390.

DOI: 10.1002/app.13393

Google Scholar
