Non-Destructive Surface Diagnostics of Tools

Abstract:

The aim of the study was to validate non-destructive diagnostics of surface of tools and metal sheets after steel grit blasting. We used replicas produced by fy Struers, known under commercial name RepliSet-F5. The replicas were extracted from surfaces of thirty specimens with PVD coatings (CrN, TiCN) and from flat specimens after steel grit blasting. Qualitative and quantitative parameters characteristic of surface morphology were determined by means of an optical profilometer, and confocal microscope was used for surface contactless metrology measurements. We observed a qualitative coincidence of morphological images of original surfaces and replicas. The values of the quantitative parameter Sa (Arithmetic mean height according to ISO 25178) of surfaces and replicas extracted from them differed at the second decimal place. Replicas document well the surface morphology and allow one to obtain information about the state of surface in difficult-to-access sites of the tools or constructions.
