Ammonia Gas Sensor Based on Chitosan Biopolymer

Abstract:

Ammonia classified as one of the hazardous chemical to environment and human. Therefore, monitoring the ammonia in air is vital. Chitosan film was selected as a sensing material for ammonia detection in this study. Chitosan powder was dissolved in 2% of acetic acid to form chitosan solution gel. It was subsequently deposited on patterned electrode by using electrochemical deposition technique. The response of the chitosan sensor towards ammonia was tested via electrical testing by exposing different ammonia concentration ranging from 20 ppm, 100 ppm, 200 ppm, and 300 ppm using air exposure technique. The response of the chitosan sensor towards ammonia was recorded as output voltage. Sensor properties which include sensitivity, stability, recovery, and repeatability were studied. The electrical result showed that the response of chitosan sensor increases as the ammonia concentration increases. All the sensing properties were achieved. Finally, the structure characterization of the chitosan was studied using Fourier Transform Infrared Spectroscopy (FTIR). The appearance of N-H and O-H groups in FTIR spectrum of chitosan film provides evidence that the domain functional group exist in chitosan after it was processed into film.

• Periodical: Materials Science Forum (Volume 819)
• Pages: 429-434
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.819.429
• Online since: June 2015
• Authors: Devi Shantini Chandrasakaran, Irwana Nainggolan, Tulus Ikhsan, Mohd Nazree B. Derman
• Keywords: Ammonia, Chitosan, Electrochemical Deposition

References

[1] N. Ellina, M. Ahmad, J. Abdullah, H. Sidek, and L. Yook, Biosensor based on glutamate dehydrogenase immobilized in chitosan for the determination of ammonium in water samples, Analytical Biochemistry. 388 (2009) 28-32.

DOI: 10.1016/j.ab.2009.02.005

[2] S. Pandey, G. K. Goswami, and K. K. Nanda, Green synthesis of polysaccharide / gold nanoparticle nanocomposite : an efficient ammonia sensor, Carbohydrate Polymers. 94 (2013) 229-234.

DOI: 10.1016/j.carbpol.2013.01.009

[3] R. Pandeeswari and B. G. Jeyaprakash, High sensing response of -Ga 2 O 3 thin film towards ammonia vapours : Influencing factors at room temperature, Sensors & Actuators: B. Chemical. 195 (2014) 206-214.

DOI: 10.1016/j.snb.2014.01.025

[4] Q. Wang et al., Ammonia sensing behaviors of TiO2-PANI/PA6 composite nanofibers, sensors (Peterborough, NH), 2012, pp.17046-17057.

DOI: 10.3390/s121217046

[5] M. Castroa, B. Kumara, J.F. Feller, Z. Haddib, A. Amari, B. Bouchikhi, Novel e-nose for the discrimination of volatile organic biomarkers with an array of carbon nanotubes (CNT) conductive polymer nanocomposites (CPC) sensors, Sensors and Actuators B. 159 (2011).

DOI: 10.1016/j.snb.2011.06.073

[6] L. Aba, Y. Yusuf, D. Siswanta, and K. Triyana, Sensitivity improvement of ammonia gas sensor based on poly (3, 4-ethylenedioxythiophene ): poly (styrenesulfonate) by employing doping of bromocresol green, Nanotechnology. 2014 (2014) 1-5.

DOI: 10.1155/2014/864274

[7] P. Stamenov, R. Madathil, and J. M. D. Coey, Chemical Dynamic response of ammonia sensors constructed from polyaniline nanofibre films with varying morphology, Sensors & Actuators: B. Chemical. 161 (2012) 989-999.

DOI: 10.1016/j.snb.2011.11.082

[8] R. G. Bavane, A. M. Mahajan, M. D. Shirsat, and R. B. Gore, Council for innovative research, Film. 3 (2013) 241-248.

[9] S. A. Ghani, A. Zakaria, and A. Y. Shakaff, Enhancing conductive polymer performance using eggshell for ammonia sensor. 23 (2012) 73-83.

[10] P. Dykstra, J. Hao, S. T. Koev, G. F. Payne, L. Yu, and R. Ghodssi: (2009). An optical MEMS sensor utilizing a chitosan film for catechol detection. Sensors and Actuators B. 138 (2009) 64–70.

DOI: 10.1016/j.snb.2009.01.065

[11] A. Bouvree, M. Castro, Y. Grohens, and M. Rinaudo, Conductive polymer nano-bio composites ( CPC ): Chitosan-carbon nanoparticle a good candidate to design polar vapour sensors, Sensors And Actuators. 138 (2009) 138-147.

DOI: 10.1016/j.snb.2009.02.022

[12] D. Feng, F. Wang, and Z. Chen, Chemical Electrochemical glucose sensor based on one-step construction of gold nanoparticle – chitosan composite film, Sensors and Actuators. 138 (2009) 539-544.

DOI: 10.1016/j.snb.2009.02.048

[13] B. Kumar, M. Castro, and J. Lu, Conductive bio-polymer nano-composites ( CPC ): Chitosan-carbon nanotube transducers assembled via spray layer-by-layer for volatile organic compound sensing, Talanta. 81 (2010) 908-915.

DOI: 10.1016/j.talanta.2010.01.036

[14] R. Pauliukaite, M. E. Ghica, O. Fatibello-filho, and C. M. A. Brett, Electrochemical impedance studies of chitosan-modified electrodes for application in electrochemical sensors and biosensors, Electrochimica Acta. 55 (2010) 6239-6247.

DOI: 10.1016/j.electacta.2009.09.055

[15] W. Li, D. M. Jang, S. Y. An, D. Kim, S. -ku Hong, and H. Kim, Polyaniline – chitosan nanocomposite : high performance hydrogen sensor from new principle, Sensors & Actuators: B. Chemical. 160 (2011)1020-1025.

DOI: 10.1016/j.snb.2011.09.020

[16] T. Ikhsan, I. Nainggolan, S. Derita, K. Rafezi, and Z. Arifin, Sensors The sensing mechanism and detection of low concentration acetone using chitosan-based sensors, " Sensors & Actuators: B. Chemical. 177 (2013) 522-528.

DOI: 10.1016/j.snb.2012.11.063

[17] D. Du, One-step electrochemically deposited interface of chitosan – gold nanoparticles for acetylcholinesterase biosensor design, Journal of Electroanalytical Chemistry. 605 (2007) 53-60.

DOI: 10.1016/j.jelechem.2007.03.013

[18] S. Yalçınkaya, C. Demetgül, M. Timur, and N. Çolak, Electrochemical synthesis and characterization of polypyrrole / chitosan composite on platinum electrode : Its electrochemical and thermal behaviors, Carbohydrate Polymers. 79 (2010) 908-913.

DOI: 10.1016/j.carbpol.2009.10.022

[19] T. Thanpitcha, A. Sirivat, A. M. Jamieson, and R. Rujiravanit: Preparation and characterization of polyaniline/chitosan blend film, Carbohydrate Polymers. 64 (2006) 560-568.

DOI: 10.1016/j.carbpol.2005.11.026

[20] R. Derrick Michele., Dusan Stulik., M. Landry , James: Infrared Spectroscopy in Conservation Science, Scientific tools for Conservation, The Getty Conservation Institute Los Angeles, 1999, pp.93-98.
