Innovative Concepts for the Use of Composite Material Solutions in the Production of Automotive Cylinder Heads

Abstract:

This paper documents the initially made and generally applicable systematisation and classification for optimised design of automotive cylinder heads by using hybrid compound material solutions. Proceeding from this background, different technical variants for design and manufacture of cylinder heads are presented. The intention is to combine different materials, so that locally different stresses in modern cylinder heads may be taken up through the specific use of appropriate materials. On the basis of fundamental investigations into the bonding behaviour of different materials, appropriate opportunities for an effective reduction resp. overcoming of the interfering oxide layer are derived. With this in view new design approaches are presented. As the basis for assessment and evaluation of their performance potential different FEM and CFD calculations for temperature field analysis, strength prognosis and fatigue strength are shown. Finally special casting tests regarding the practical feasibility of the appropriate conceptions in production are presented.

• Periodical: Materials Science Forum (Volumes 825-826)
• Pages: 715-723
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.825-826.715
• Online since: July 2015
• Authors: Stefan Scharf*, Rüdiger Baehr
• Keywords: Compound Casting, Concept Variants, Cylinder Head, Material Connection

References

[1] H. Sorger, F. Zieher, U. Sauerwein, W. Schoeffmann, Highly loaded cylinder heads for gasoline and diesel engines. Trends and potentials, MTZ 69 (02/2008) 104–113.

DOI: 10.1007/bf03226885

[2] R. Golloch, Downsizing for internal combustion engines. An effective approach to reducing fuel consumption, Springer, Berlin, Heidelberg, New York, (2005).

[3] S. Scharf, Concepts for manufacturing cylinder heads in composite casting, Doctoral thesis, University of Magdeburg, Faculty of Mechanical Engineering, (2014).

[4] V. Taran, Development of a technology for manufacturing a gradient-cast aluminium cylinder head, Doctoral thesis, University of Magdeburg, Faculty of Mechanical Engineering, (2001).

[5] K. Kerber, A method for composite casting of the light metals aluminium and magnesium by die casting, Doctoral thesis, Leibnitz-University Hannover, Institute of Materials Science, (2011).

[6] F. Ostermann, Application technology aluminium, Springer, Berlin, Heidelberg, New York, (1998).
