Influence of Process Conditions on Spangle Size of 55%Al-Zn Alloy Coated Steel Sheet

Abstract:

Statistic analyses of industrial experimental datum were done to investigate the effect of pretreatment process, hot-dip process and posttreatment process on spangle size of hot-dip 55%Al-Zn alloy coated steel sheet. The results show that, with the decrease of concentration of degreasing solution, the decrease of RTF dew point temperature, the decrease of temperature at which strip entering into Al-Zn bath, and the increase of injection pressure of air knife, spangle size decreases; with the increase of hydrogen content in RTF, spangle size decreases firstly and then tends to be stable; with the increase of bath temperature, spangle size increases firstly and then decreases; The hot-dip time, the distance between air knife and steel strip, the height of air knife from Al-Zn bath, and the blowing rate of cooling fan have little effect on spangle size; the addition of mixed rare earth doesn’t affect spangle size, while the addition of titanium with trace amount leads to the decrease of spangle size.

• Periodical: Materials Science Forum (Volume 889)
• Pages: 127-132
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.889.127
• Online since: March 2017
• Authors: Tai Xiong Guo*, Quan Xu, Chang Rong Ran, Xue Qiang Dong
• Keywords: 55%Al-Zn Alloy Coating, Process Conditions, Rare Earth, Spangle Size, Titanium

References

[1] A. Humayun, Production & Performance of 55%Al-Zn Coated Sheet [C]. Chicago, USA: Galvatech'1995, 1995: 443-447.

[2] M.S. Yuan, Properties and Application for Galvalume Coating Steel Sheet [J] . World Iron Steel, 2004, (3): 70-72.

[3] S.J. Park, K.W. Jung, H.S. Koh, Production of Heavy Gauged HY-Galvalume in Hyundai HYSCO [J]. Corrosion Science and Technology, 2011, 10(5): 11-15.

[4] J.F. Willem, S. Claessens, H. Cormil, Solidification Mechanisms of Aluzinc Coatings Effect on Spangle Size [C]. Brussels, Belgium: Galvatech'2001, 2001: 401–408.

[5] B.J. Xu, D. Phelan, R. Dippenaar, Nucleation During Solidification of 55wt%Al-Zn-Si Alloy Coatings [C]. Chicago, USA: Galvatech'04, 1994: 713-721.

[6] K. Tokuda, N. Shimoda, Y. Morimoto. A Study of Spangle Nucleation Process in 55%Al-Zn-1. 6%Si Coatings [C]. Genova, Italy: Galvatech'2011, (2011).

[7] R.Y. Chen, D. Yuen. Microstructure and Crystallography of Zn-55Al-1. 6Si Coating Spangle on Steel [J]. Metallurgical and Materials Transactions A, 2012, 43A: 4711-4723.

DOI: 10.1007/s11661-012-1259-5

[8] A. Semoroz, Y. Durandet, M. Rappaz, EBSD Characterization of Dendrite Growth Directions, Texture and Misorientations in Hot-dipped Al-Zn-Si Coatings [J]. Acta mater, 2001, 49: 529～541.

DOI: 10.1016/s1359-6454(00)00322-0

[9] Y.L. Ren, N.M. Wen, Z.P. Zhu, Study of the Spangle Size of 55%AI-Zn-Si Steel [J]. Baosteel Technical Research, 2014, 8(4): 41-47.

[10] S. Hikino, T. Matsunaga, M. Aral, etc. Influence of Coating Condition on Spangles of 55%Al-Zn Alloy Coated Steel Sheet [J]. La revue de Metallurgle-ATS-JS. 1997: 168-169.

[11] D.C. Bae, H.S. Shin, S.K. Chang, Influence of processing variables on coating characteristics of 55%Al-Zn coated steel sheet [J]. CAMP-ISIJ, 1996, 9: 521.

[12] K.J. Park, C.K. Park, Y.H. Lee, Improvement of Spangle Size Uniformity at 55%Al-Zn Coating Line [C]. Jejiu, Korea: 2009 Asia-Pacific Galvanizing Conference, (2009).

[13] B. Xu, D. Phelan, R. Dippenaar, Role of Silicon in Solidification Microstructure in Hot-dipped 55 wt. %Al-Zn-Si Coatings [J]. Materials Science and Engineering A, 2008, 473: 76～80.

DOI: 10.1016/j.msea.2007.03.110

[14] Y. Durandet, L. Strezov, N. Ebrill, Formation of Al-Zn-Si Coatings on Low Carbon Steel Substrates [C]. Tokyo, Japan: Galvatech'98, (1998).

[15] T.X. Guo, X.Q. Dong, S.H. Deng, Influence of Rare Earth on Hot-dipped 55%Al-Zn Alloy Coating [J]. Advanced Materials Research, 2013, 774-776: 1132-1136.

DOI: 10.4028/www.scientific.net/amr.774-776.1132

[16] T.X. Guo, C.S. Liu, Y.L. Zhou, etc. Influence of Titanium on Hot-dip 55%Al-Zn Alloy Coating [C]. 2014 International Conference on Manufacturing and Engineering Technology (ICMET 2014), 2014, Sanya, China. Manufacturing and Engineering Technology, Sheng&Wang (Eds), © 2015 Taylor & Francis Group, ISSBN 978-1-138-02645-2, 283-286.

DOI: 10.1201/b17735-62

[17] K. Tokuda, N. Shimoda, Y. Morimoto, A Study of Spangle Nucleation Process in 55%Al-Zn-1. 6%Si Coatings [C]. Genova, Italy: Galvatech'2011, (2011).

[18] R.Y. Chen, D. J. Willis. The Behavior of Silicon in the Solidification of Zn-55Al-1. 6Si Coating on Steel [J]. Metallurgical and Materials Transactions A, 2005, 36A, 117-128.

DOI: 10.1007/s11661-005-0144-x

[19] G. X. Wu, J. Y. Zhang, Q. Li, Microstructure and Thickness of 55 pct Al-Zn-1. 6 pct Si-0. 2 pctRE Hot-Dip Coatings: Experiment, Thermodynamic and First-Principles Study [J]. Metallurgical and Material Transactions B, 2012, 43B, 198-205.

DOI: 10.1007/s11663-011-9578-2
