Damper as a Rigid Insert for Rigid Bus Structures Oscillation Damping

Abstract:

One of the main problems in a design of rigid bus structures in open switchgears devices is a structural stabilization under the influence of various dynamic loads. The implementation of rigid bus structures with large spans of pipe-bus showed a real danger of the wind resonance for cylindrical pipe-bus structures (aeroelastic oscillations). This phenomenon is dangerous in that at low wind speeds there are intense pipe's oscillations in vertical plane, adding to the static loads an essential dynamic component. Its level is comparable with the loads from the weight of the structures and can, in combination with the rest loads, cause stresses close to the maximum admissible for the 1^st group of limit states. The problem of reducing the level of structural oscillations in many cases is associated with the need to increase the rigidity and reduce the material consumption, but it's important to meet the technological requirements imposed by operating conditions and protect people from harmful vibration. In a paper are considering a new method for damping oscillations for rigid bus structures under the action of a wind vortex excitation – damper as a rigid insert. Is presented a mathematical model of the joint work of the rigid bus structure with the damper as the rigid insert. Have carried out analytical researches of the joint work of the rigid bus structure with the damper as the rigid insert.

• Periodical: Materials Science Forum (Volume 931)
• Pages: 14-18
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.931.14
• Online since: September 2018
• Authors: Serafim A. Fomenko, Igor M. Garanzha*, Anton V. Tanasoglo
• Keywords: Differential Equations of Transverse Oscillations, Eddy Excitation of Wind, Oscillation Damper, Rigid Bus

References

[1] E.V. Denisov, S.A. Fomenko Features of the rigid bus structures application in open switchgears, J. Metal Const. 1(17) (2011) 13-23.

[2] A. Placzek, J-F. Sigrist, A. Hamdouni. Numerical simulation of an oscillating cylinder in a cross-flow at low reynolds number: Forced and free oscillations. J. Comp. and Fluids, 38(1) (2009) 80-100.

DOI: 10.1016/j.compfluid.2008.01.007

[3] L. Carassale, Analysis of aerodynamic pressure measurements by dynamic coherent structures / L. Carassale J. Probab. Eng. Mech. 28 (2012) 66–74.

DOI: 10.1016/j.probengmech.2011.08.010

[4] Eurocode 1: Actions on Structures – General Actions – Part 1-4: Wind Actions [Text]. – Will supersede ENV 199124:1995; introduced January 2004.– Brussels: CEN/TC250,2002.– 148р.

[5] J. D. Holmes Wind Loading of Structures, second ed., Taylor & Francis, New York, (2007).

[6] L. Tian, J. Zhang, and W. Zhang. Nonlinear characteristics of vortex-induced vibration at low reynolds number J. Comm. in Nonlin. Sc. and Num. Simul. 16(7) (2011) 2753–2771.

DOI: 10.1016/j.cnsns.2010.10.014

[7] K. Togbenou, Y. Li, N. Chen, H. Liao An efficient simulation method for vertically distributed stochastic wind velocity field based on approximate piecewise wind spectrum, J.of Wind Eng. and Ind. Aerodyn. 151 (2016) 48–59.

DOI: 10.1016/j.jweia.2016.01.005

[8] Y. Uematsu, C. Koo Wind-tunnel study of wind loads on circular cylindrical structures, J. of Wind Eng. 33 (2008) 17-25.

[9] SUO 40.132385941-39:2011 Designing of the rigid bus in open switchgears from 110 to 750 kV. Methodical instructions, Institute «Ukrenergosetproekt», Kiev, (2010).

[10] OS 56947007-29.060.10.006-2008. Methodical instructions for the calculation and testing of a rigid bus ОSG 110-500 kV. «Rosseti Federal Grid Company», Moscow, (2008).

[11] Design Guide for Rural Substations: RUS Bulletin 1724E-300. Official publication. Washington: United States Department of Agriculture, (2001).

[12] Ye. V. Gorokhov, V. F. Mushchanov, V. V. Kulyabko Ways of antihunting rigid conductors structures of outdoor switchgears of the power supply network construction, Materials of the 10th Int. Conf. «Mod. Build. Mat., Struc. and Techn.». 10 (2010).

[13] Patent 2402129 Russian Federation, MPK F16F15/00. Device for transmission and distribution of electricity /Dolin А.,Dolin S.; decl.25.08.2008; publ.20.10.2010,Bulletin № 29.

[14] Patent  40094 Ukraine, MPK F16F 15/00. Aerodynamic method for suppression of wind resonance flexural vibrations of a pipe / Kulyabko V., Mushchanov V., Maslovskyi A., Denisov E.; decl. 20.10.2008; publ. 25.03.2009, Bulletin № 6.

[15] Patent  40099 Ukraine, MPK F16F 15/00. String damper for damping the pipe bending oscillations of the wind resonance / Kulyabko V., Mushchanov V., Maslovskyi A., Denisov E.; decl. 20.10.2008 ; publ. 25.03.2009, Bulletin № 6.

[16] Patent 40431 Ukraine, MPK F16F 15/00. The damping method of the fundamental tone for bending oscillations of a rigid bus / Kulyabko V., Mushchanov V., Maslovskyi A., Denisov E.; decl. 23.10.2008 ; publ. 10.04.2009, Bulletin № 7.

[17] Patent 40434 Ukraine, MPK F16F 15/00. The damper of bending oscillations / Kulyabko V., Mushchanov V., Maslovskyi A., Denisov E., Mikheev A.; decl. 27.10.2008; publ. 10.04.2009, Bulletin № 7.

[18] Patent 40435 Ukraine, MPK F16F 15/00. The joint of cables junction with rigid elements / Kulyabko V., Mushchanov V., Maslovskyi A., Denisov E.; decl. 27.10.2008; publ. 10.04.2009, Bulletin № 7.
