Structural Stability of Hafnia-Based Materials at Ultra-High Temperature

Abstract:

This study assesses the structural stability at ultra-high temperature of the following selected compositions: 6.5 and 14 mol. % of RE₂O₃ (RE = Dy, Y, Er, Yb, and Lu) doped HfO₂. Under thermal cycling and thermal shock, the structural stability was evaluated at 2400°C with water vapor flux using a specific test bench with a 3 kW CO₂ laser. The cubic phase stability, which is theoretically important in the broad temperature range from 25 to 2800°C, was determined by a quantitative analysis of the X-ray diffractograms. Fully and partially stabilized HfO₂, obtained respectively with 14 mol. % and 6.5 mol. % of dopants, showed different behaviors to thermal damage. Thermal expansion was measured up to 1650°C to anticipate dimensional changes of these stabilized samples and to be able to design an optimized material solution fitting with future combustion chamber requirements. All of these results were then considered in order to exhibit a trend on the thermal stability at 2400°C of the ionic radius of the dopants and their optimal doping rates.

• Periodical: Materials Science Forum (Volume 941)
• Pages: 1972-1977
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.941.1972
• Online since: December 2018
• Authors: Louise Sévin*, Aurélie Julian-Jankowiak, Jean François Justin, Cécile Langlade, Pierre Bertrand, Nicolas Pelletier
• Keywords: HfO₂, Phase Stability, Spacecraft Propulsion, Thermal Expansion, UHTC

References

[1] R.P. Haggerty, P. Sarin, Z.D. Apostolov, P.E. Driemeyer, W.M. Kriven, Thermal Expansion of HfO2 and ZrO2, J. Am. Ceram. Soc. 97 (2014) 2213–2222.

DOI: 10.1111/jace.12975

[2] S. Stecura, W.J. Campbell, United States, Bureau of Mines, Thermal expansion and phase inversion of rare-earth oxides, U.S. Department of the Interior, Bureau of Mines, Washington, D.C., (1961).

DOI: 10.2172/4840970

[3] J.D.W. Buckley, Effects of Cyclic Heating and Thermal Shock on Hafnia Stabilized with Calcia, Magnesia, and Yttria, 1969. https://ntrs.nasa.gov/search.jsp?R=19690025169 (accessed February 8, 2018).

[4] J.W. Fergus, Zirconia and Pyrochlore Oxides for Thermal Barrier Coatings in Gas Turbine Engines, Metall. Mater. Trans. E. 1 (2014) 118–131.

DOI: 10.1007/s40553-014-0012-y

[5] Extreme Temperature Coatings for Future Gas Turbine Engines, ResearchGate. (n.d.). https://www.researchgate.net/publication/267504229_Extreme_Temperature_Coatings_for_Future_Gas_Turbine_Engines (accessed August 22, 2017).

DOI: 10.1115/1.4027186

[6] D. Zhu, Advanced Environmental Barrier Coating Development for SiC/SiC Ceramic Matrix Composites: NASA's Perspectives, (2016). https://ntrs.nasa.gov/search.jsp?R=20160014698 (accessed February 8, 2018).

[7] D. Zhu, Hafnia-Based Materials Developed for Advanced Thermal/Environmental Barrier Coating Applications, 2004. https://ntrs.nasa.gov/search.jsp?R=20050192261 (accessed February 8, 2018).

[8] J. Wang, H.P. Li, R. Stevens, Hafnia and hafnia-toughened ceramics, J. Mater. Sci. 27 (1992) 5397–5430.

DOI: 10.1007/bf00541601

[9] E.R. Andrievskaya, Phase equilibria in the refractory oxide systems of zirconia, hafnia and yttria with rare-earth oxides, J. Eur. Ceram. Soc. 28 (2008) 2363–2388.

DOI: 10.1016/j.jeurceramsoc.2008.01.009

[10] P. Duran, C. Pascual, Phase equilibria and ordering in the system HfO2-Yb2O3, J. Mater. Sci. 19 (1984) 1178–1184.

DOI: 10.1007/bf01120027

[11] H. IBEGAZENE, Etude microstructurale de la stabilité thermique de phases métastables dans les systèmes à base de ZrO2, Hf02, et d'oxydes de terres rares, Onera, (1996).

[12] G. Fantozzi, J.-C. Niepce, G. Bonnefont, Les céramiques industrielles: Propriétés, mise en forme et applications, Dunod, (2013).

DOI: 10.3917/dunod.fanto.2013.01.0367
