Effect of the Quenching Temperature on the Phase Composition and Youngʹs Modulus of Corrosion-Resistant and Biocompatible Titanium Alloys

Abstract:

The relationship between the phase composition and the Young’s modulus in quenched PT-7M, Ti-6Al-7Nb, BT16 titanium alloys has been studied using the structural analysis, thermodynamic calculations in the Thermo-Calc software and micro-indentation. It is found that the nature of the change in the Young’s modulus in the investigated titanium alloys after quenching from the two-phase α+β-region depends on the chemical composition of the alloy, which determines the nature of the observed metastable phases (α', α", ω, β). The correlation between the extreme change in the Young’s modulus from the quenching temperature and the so-called interatomic bonding force (F_b) calculated from the electronic structure parameters of the α, α', β phases was shown for the Ti-6Al-7Nb alloy. The relationship between the limits of the Young’s modulus of the investigated alloys during quenching with the level of their alloying with α-and β-stabilizers is shown.

• Periodical: Materials Science Forum (Volume 946)
• Pages: 309-314
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.946.309
• Online since: February 2019
• Authors: Anatoliy G. Illarionov*, Stella V. Grib, A.V. Huppeev
• Keywords: Biocompatible Titanium Alloys, Phase, Quenching, Young’s Modulus

References

[1] M. Niinomi, Mechanical biocompatibilities of titanium alloys for biomedical applications, Journal of the mechanical behavior of biomedical materials. I (2008) 30-42.

DOI: 10.1016/j.jmbbm.2007.07.001

[2] M. Geeta, A.K. Singh, R. Asokamani, A.K. Gogia, Ti based biomaterials, the ultimate choice for orthopedic implants – A review. Progress in Materials Science. 54 (2009) 397-425.

DOI: 10.1016/j.pmatsci.2008.06.004

[3] A. Illarionov, S. Belikov, S. Grib, A. Yurovskikh, Metallic materials for medical use, MATEC Web Conferences 132. 03003 (2017).

DOI: 10.1051/matecconf/201713203003

[4] E.W. Collings, The Physical Metallurgy of Titanium Alloys, Metals Park, OH: American Society for Metals, (1984).

[5] Y.T. Lee, G. Welsch, Young's Modulus and Damping Capacity of Ti-6Al-4V Alloy as a Function of Heat-Treatment and Oxygen Concentration, Materials Science and Engineering. A128 (1990) 77-89.

DOI: 10.1016/0921-5093(90)90097-m

[6] B.A. Kolachev, I.S. Polkin, V.D. Talalayev, Titanium alloys of different countries, Moscow, VILS, (2000).

[7] M. Semlitsch, F. Stabu, H. Weber, Titanium-aluminium-niobium alloy, development for biocompatible, high strength surgical implants, Biomedizinische Technik, Biomedical Engineering.  30(12) (1985) 334–339.

DOI: 10.1515/bmte.1985.30.12.334

[8] A.V. Karlov, V.P. Shakhov, Systems of external fixation and regulator mechanisms of optimal biomechanics, SST, Tomsk. (2001).

[9] W.C. Oliver, G.M. Pharr, An improved technique for determining hardness and elastic-modulus using load and displacement sensing indentation experiments, J. Mater. Res. 7 (1992) 1564-1583.

DOI: 10.1557/jmr.1992.1564

[10] A.A. Ilyin, B.A. Kolachev I.S. Polkin, Titanium alloys. Composition, structure, properties, Moscow, VILS-MATI, (2009).

[11] R. Boyer, G. Welsch, E.W. Collings, Materials Properties Handbook: Titanium Alloys, ASM International, The Material Information Society, (1994).

[12] A.G. Illarionov., M.S. Karabanalov, S.I. Stepanov, Formation of structure, phase composition and properties in biocompatible titanium alloy due to heat treatment, Metal Science and Heat Treatment. 52(9-10) (2011) 481-486.

DOI: 10.1007/s11041-010-9304-8

[13] A. Illarionov, M. Karabanalov, A. Korelin, S. Novokreschenov, Quenching temperature influence on elastic and hardness behavior in a biocompatible Ti-based alloy, MATEC Web Conferences 132. 03008 (2017).

DOI: 10.1051/matecconf/201713203008

[14] Li You, Xiping Song, A study of low Young's modulus Ti-Nb-Zr alloys using d electrons alloy theory, Scripta Materialia. 67 (2012) 57-60.

DOI: 10.1016/j.scriptamat.2012.03.020

[15] J.C. Slater, Atomic shielding constants, Physical Review. 36 (1930) 57-64.

[16] M. Abdel-Hady, K. Hinoshita, M. Morinaga, General approach to phase stability and elastic properties of β-type Ti-alloys using electronic parameters, Scripta Materialia. 55(5) (2006) 477-480.

DOI: 10.1016/j.scriptamat.2006.04.022

[17] M. Morinaga, Alloy design based on molecular orbital method, Materials Transactions. 57(3) (2016) 213-226.

DOI: 10.2320/matertrans.m2015418

[18] V.N. Moiseev, Yigh-strength titanium alloy VT16 for manufacturing fasteners by method of cold deformation, Metal Science and Heat Treatment. 43(1-2) (2001) 73-77.

[19] A.A. Popov, A.G. Illarionov, S.I. Stepanov, O.M. Ivasishin, Effect of quenching temperature on structure and properties of titanium alloy: Physicomechanical properties, Physics of Metals and Metallography. 115(5) (2014) 517-522.

DOI: 10.1134/s0031918x1405007x

[20] A.A. Popov, A.G. Illarionov, S.I. Stepanov, O.A. Elkina, O.M. Ivasishin, Effect of quenching temperature on structure and properties of titanium alloy: Structure and phase composition, Physics of Metals and Metallography. 115(5) (2014) 507-516.

DOI: 10.1134/s0031918x14050068
