Assessment of Mold Filling Rate Influence on Amount of Oxide Films in Castings by Numerical Simulation

Abstract:

The influence of the mold filling rate on the content of oxide films in aluminum alloy castings is considered. The existing methods for estimating the probability of formation and entrainment of oxide films in the bulk of the liquid, which are associated with surface disturbances during the melt flow through the channels of the mold, are analyzed. A criterion for estimating oxide impurities in the melt using numerical process modeling is proposed. A comparative analysis of the results of numerical simulation with the data of practical experiments obtained by M. V. Sharov and N. M. Galdin was performed. This comparative analysis and experience in the development of technological processes for shaped castings showed the possibility of using the criterion in numerical modeling.

• Periodical: Materials Science Forum (Volume 989)
• Pages: 595-599
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.989.595
• Online since: May 2020
• Authors: O.A. Zarubina*, A.Yu. Korotchenko, A.M. Zarubin
• Keywords: Aluminum Alloy, Free Surface, Gravity Filling, Oxide Films, Surface Perturbation

References

[1] Galdin N. M. Litnikovye sistemy dlja otlivok iz legkih splavov [Casting systems for light alloy castings]. Moscow, Mashinostroenie Publ., (1978).

[2] M. A. M. El-Sayed, Double Oxide Film Defects and Mechanical Properties in Aluminium Alloys, University of Birmingham, Birmingham, UK, (2012).

[3] Ludwig, T.H., et al., Influence of oxide additions on the porosity development and mechanical properties of A356 aluminium alloy castings. International Journal of Metalcasting, 6 (2012) 41-50.

DOI: 10.1007/bf03355526

[4] Campbell, J., An overview of the effects of bifilms on the structure and properties of cast alloys,, Metallurgical and Materials Transactions B, 37(6) (2006) 857–863.

DOI: 10.1007/bf02735006

[5] N., Green and J., Campbell, Influence of oxide film filling defects on the strength of Al-7Si-Mg alloy castings,, AFS Transactions,102 (1994) 341–347.

[6] Campbell, J., The New Metallurgy of Cast Metals: Casting, 2nd Edition, Butterworth-Heinemann, (2003).

[7] Musijachenko A. S. Maximum permissible melt flow rates in the mold. Liteinoe proizvodstvo [Foundru], 2 (1987) 16-17.

[8] N.M. Galdin, V.V. Chistjakov, A.A. Shatul'skij. Litnikovye sistemy i pribyli dlja fasonnyh otlivok [Gating systems and feeders for shaped castings]. Moscow, Mashinostroenie Publ., (1992).

[9] Reilly, C., Green, N. R., Jolly, M. R., Gebelin, J. C., Using the Calculated Fr Number for Quality Assessment of Casting Filling Methods,, Modelling of casting, welding and advanced solidification process XII (Vancouver, June7-14, 2009), Vancouver, Canada, (2009) 419-426.

[10] N.W., Lai, W. D., Griffiths, and J., Campbell, Modelling of the potential for oxide film entrainment in light metal alloy castings,, In D.M. Stefanescu, J.A. Warren, M.R. Jolly, and J. Campbell, editors, Modeling of Casting, Welding and Advanced Solidification Processes- X, pages 415–422, Destin, FL, 2003. TMS (The Minerals, Metals & Materials Society).

[11] M.R. Barkhudarov and C.W. Hirt. Tracking defects. Technical report, Flow Science, Inc., (1999).

[12] Yang, X., Huang, X., Dia, X., Campbell, J., Tatler, J., Numerical Modelling of Entrainment of Oxide Film Defects in Filling of Aluminium Alloy Castings,, Int. J. Cast Met. Res., 17 (2004) 321–331.

DOI: 10.1179/136404604225022748

[13] Dai, X., Jolly, M., Yang, X., Campbell, J., Modelling of Liquid Metal Flow and Oxide Film Defects in Filling of Aluminum Alloy Castings,, IOP Conference Series: Materials Science and Engineering, 33 (2012) 1–10.

DOI: 10.1088/1757-899x/33/1/012073

[14] M.P. Silva, D.E.J. Talbot, Oxidation of liquid aluminum-magnesium alloys. Light Metals, (1989) 1035-1040.

[15] A.V. Kurdyumov, S. V. Inkin, V. S. Chulkov, N. I. Grafas. Flyusovaya obrabotka i fil'trovanie alyuminievykh rasplavov [Flux treatment and filtration of aluminum melts]. Moscow, Metallurgiya Publ., (1980).

[16] Chistyakov V. V. Metody podobiya i razmernostey v liteynoy gidravlike [Methods of similarity and dimensions in foundry hydraulics]. Moscow, Mashinostroenie Publ., (1990).

[17] Weigel, J., Fromm, E., Determination of Hydrogen Absorption and Desorption Processes in Aluminum Melts by Continuous Hydrogen Activity Measurements,, Metallurgical transactions B, 21B(October) (1990) 855-860.

DOI: 10.1007/bf02657810

[18] Nayebi, B., Divandari, M., Characteristics of dynamically formed oxide films on molten aluminium,, International Journal of Cast Metals Research, 25(5) (2012) 270-276.

DOI: 10.1179/1743133612y.0000000026

[19] Sharov M. V., Galdin N.M. Effect of flow turbulence on the formation of contamination in aluminum alloys Liteinoe proizvodstvo [Foundru], 1 (1971) 9-13.

[20] Kendall, M. G., and P. A. P. Moran. Geometrical Probability. London, Griffin, (1963).

[21] Zarubin A. M. On the score casting porosity. Liteinoe proizvodstvo [Foundru], 4 (1987) 15-16.
