Dynamics of a Mechatronic System with Flexible Vertical Rotor

Abstract:

The paper is dedicated to research on flexible rotor systems with anisotropic rotor material properties. In addition, the anisotropy of rotor supports alters the rotor system resonance frequencies and the machine has to pass till it attains the operating angular speed. This phenomenon of rotor vibration is observed in vertical rotors. The aim of this work is to compare experimental vibration measurements and results of theoretical modeling. In the paper theoretical model, created from physical one of really existing rotor system is described. Collected experimental data of rotor vibrations in bearings are compared with results of theoretically derived equations. The results of theoretical modeling and research enables for estimation of a more precise technical condition of the rotor system both after the overhaul and during the maintenance and thus to avoid unexpected breakdowns, especially concerning the fatigue development in ball bearing elements.

• Periodical: Solid State Phenomena (Volume 113)
• Pages: 223-228
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.113.223
• Online since: June 2006
• Authors: Vytautas Barzdaitis, Vytautas Žemaitis, R. Jonušas, Vytautas Kazimieras Augustaitis, Vytautas Bučinskas
• Keywords: Dynamic, Mechatronics, Rotor Systems

References

[1] A. Muszynska: Forward and Backward Precession of a Vertical Anisotropically Supported Rotor (Journal of Sound and Vibration, 192(1), 1996), pp.207-222.

DOI: 10.1006/jsvi.1996.0184

[2] V. Barzdaitis, G. Činikas: Formats of vibration monitoring data in diagnostics of rotor machines (Mechanika, Kaunas, Technologija, Nr. 2(9), 1997), pp.40-48 (In Lithuanian).

[3] L. R. Esheman: Machinery Vibration Analysis I (Willowbrook, Illinois, Vibration Institute, USA, 1999), p.149.
