Fluidity and Microstructures Characteristics of AZ 91D by Using New Type Semi-Solid Injection Process

Rudi S. Rachmat; Takuya Tamura; Kenji Miwa

doi:10.4028/www.scientific.net/SSP.116-117.534

Paper Titles

Development of In-Ladle Direct Thermal Control (DTC) Rheocasting Process
p.518

Analysis of the Age-Hardening T5 Treatment in a Al-7%Si-0.6%Mg-0.5%Cu Rheo-Cast Alloy
p.522

The Effect of Stirring Current and Stirring Time on Microstructure and Mechanical Properties in Rheo Die Casting Process
p.526

Mechanical Behavior of Processed AZ91D by Equal Channel Angular Extrusion during Semi-Solid Isothermal Compression
p.530

Fluidity and Microstructures Characteristics of AZ 91D by Using New Type Semi-Solid Injection Process
p.534

Microstructural Evolution of A206 Al Alloy by In-Ladle DTC Rheocasting
p.538

The Effect of Electromagnetic Stirring on the Semi-Solid Microstructure of High-Melting Alloys
p.542

Control of Semi-Solid Microstructure of AZ91D Mg Alloys by the Electromagnetic Stirring
p.546

Aging Behavior of Al-Cu Alloys Produced by Melt Extrusion Process
p.550

HomeSolid State PhenomenaSolid State Phenomena Vols. 116-117Fluidity and Microstructures Characteristics of AZ...

Fluidity and Microstructures Characteristics of AZ 91D by Using New Type Semi-Solid Injection Process

Abstract:

This research has been investigated fluidity and microstructures characteristics of AZ 91 D alloy using new type semi-solid injection machine. To ensure good casting products, uniform temperature distribution was required during heating in the injection cylinder of this machine. So, the injection cylinder was divided with six heating zones. Then temperature distribution in the injection cylinder was precisely controlled. AZ 91 D billets were heated to the desired temperatures in the injection cylinder, and injected into the permanent mold with injection speed about 430 mm/s. Fluidity was measured by using spiral permanent mold with the cavity of 1045 mm in length and 5 mm in thickness. The fluidity test has been done with the fraction solid from 0% - 60%. The fluidity was 905 to 153 mm for fraction solid 0% to 60%, respectively. At the fraction solid from 50% to 60% microstructures are consisted of spherical solid particles and the solid particles surrounded by liquid phase. The shape of solid particles begins to change at the fraction solid of 40%.

You might also be interested in these eBooks

Semi-Solid Processing of Alloys and Composites

View Preview

Info:

Periodical:

Solid State Phenomena (Volumes 116-117)

Pages:

534-537

DOI:

https://doi.org/10.4028/www.scientific.net/SSP.116-117.534

Citation:

Cite this paper

Online since:

October 2006

Authors:

Rudi S. Rachmat, Takuya Tamura, Kenji Miwa

Keywords:

Fluidity, Fraction Solid, Injection Process, Microstructure, Solid Particles

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] Rudi S. Rachmat, S. Kamado, N. Ikeya, T. Araki, Y. Kojima: High Temperature Strength of Semi-solid Formed Mg-Zn-Al-Ca Alloys, Materials Science Forum YR��350-351 (2000), pp.79-84.

DOI: 10.4028/www.scientific.net/msf.350-351.79

Google Scholar

[2] Kenji Miwa, Rudi S. Rachmat, Takuya Tamura: Relationship Between Volume Fraction Solid and Casting Defects on semi-solid Injection in AZ 91 D Magnesium Alloy, Journal of Japan Foundry Engineering Society, in printing, (2006).

Google Scholar

[3] Rudi S. Rachmat, Takuya Tamura, Yasuji Sakaguchi, Kenji Miwa: New Type Semi-solid Injection Process for AZ 91 D Alloy, Proceeding of the 1 st Asian Symposium on Magnesium Alloys (2005), pp.241-244.

Google Scholar

[4] Mary Jane Walzak, Ross D. Davidson, N, Steward Mc Intire, Donald Argo, Boyd R Davis: Interfacial Reaction Between SF6 and Molten Magnesium, Magnesium Technology. Ed, by. J. Hryn, TMS (The Mineral, Metals and Material Society, 2001), pp.37-41.

DOI: 10.1002/9781118805497.ch9

Google Scholar
