Experimental Investigations of MREs Behavior under the Cyclic Load

Abstract:

In the paper the experimental results of the dynamic tests of the MRE samples cured without and under magnetic field are presented and compared. The samples (55 mm diameter and 70 mm) were made of the polyurethane elastomer PU 70/30 with the admixture of the ferromagnetic particles (in this case – carbonyl iron spheres with the diameter of about 9 μm). The samples with ferromagnetic particles were cured without as well as under the external, parallel to the vertical axis of the sample, magnetic field of the 300 mT intensity. The experiments were carried out on the materials testing machine for static and dynamic loads INSTRON 8802. The machine was additionally equipped with the measurement head of 4kN scope and the magnetic coil that produces the magnetic field of the intensity up to 500 mT. Cycled load was applied to the MRE samples. In the case of the dynamic tests the sinusoid cyclic variable load was used. The applied load frequency was 1 Hz in each presented test. The samples were cyclically compressed of the 10, 15, 20 and 25 % of their height. On the base of the obtained results the force maximum values and the dumping coefficient (the energy dissipation coefficient) in each dynamic tests were calculated. The hysteresis loops in the load – displacement charts that were observed during the cyclic tests. The influence of the internal structure of the researched material on its strength behaviour is taken into consideration.

You might also be interested in these eBooks

Environmental Degradation of Engineering Materials & Materials Engineering and Technologies

View Preview

Info:

Periodical:

Solid State Phenomena (Volume 183)

Pages:

163-168

DOI:

https://doi.org/10.4028/www.scientific.net/SSP.183.163

Citation:

Cite this paper

Online since:

December 2011

Authors:

Grzegorz Slawinski, Danuta Miedzińska, Tadeusz Niezgoda, Anna Boczkowska

Keywords:

Carbonyl Iron, Magnetic Field, Magnetorheological Elastomer, Microstructure, Rheological Property, Smart Materials

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] D. Miedzinska, A. Boczkowska, K. Zubko: Numerical verification of three point bending experiment of magnetorheological elastomer (MRE) in magnetic field, Journal of Physics: Conference Series 240 (2010) 012158.

DOI: 10.1088/1742-6596/240/1/012158

Google Scholar

[2] A. Boczkowska, S. Awietjan: Urethane Magnetorheological Elastomers – Manufacturing, Microstructure and Properties, Solid State Phenomena, Volume 154, pp.107-112, (2009).

DOI: 10.4028/www.scientific.net/ssp.154.107

Google Scholar

[3] E. Coquelle: Properietes elastiques et viscoelastiques de materiaux composities adaptatifs. Du traitement de surface des charges au comportement magnetorheologique. PHD thesis, Universite de Nice Sophia-Antipolis, (2005).

Google Scholar

[4] G. Bossis, S. Lacis, A. Meunier, O. Volkova: Magnetorheological fluids, Journal of Magnetism and Magnetic Materials 252 (2002) 224-228.

DOI: 10.1016/s0304-8853(02)00680-7

Google Scholar

[5] Y. Shen, F. Golnaraghi, G.R. Heppler: Experimental Research and Modeling of Magnethoreological Elastomers, Journal of Intelligent Material Systems and Structures, 15 (2004) 27-35.

DOI: 10.1177/1045389x04039264

Google Scholar

[6] A. Boczkowska, S.F. Awietjan, R. Wroblewski: Microstructure–property relationships of urethane magnetorheological elastomers, Smart Mater. Struct. 16 , 1924–1930, (2007).

DOI: 10.1088/0964-1726/16/5/049

Google Scholar

[7] M.R. Jolly, J.D. Carlson, B.C. Munoz: A model of the behavior of magnetorheological materials, Smart Mater. Struct. 5 (1996) 607-614.

Google Scholar

[8] L.C. Davis: Model of magnetorheological elastomers, J. Appl. Phys., 85 (1999) 3348–51.

Google Scholar

[9] Y.S. Zhu, X.L. Gong, H. Dang, X.Z. Zhang and P.Q. Zhang: Numerical analysis on magnetic-induced shear modulus of magnetorheological elastomers based on multi-chain model, Chin. J. Chem. Phys. 19 (2006) 126–30.

DOI: 10.1360/cjcp2006.19(2).126.5

Google Scholar

[10] L. Chen, X.L. Gong, W.H. Li: Microstructures and viscoelastic properties of anisotropic magnetorheological elastomers, Smart Mater. Struct., 16 (2007) 2645–2650.

DOI: 10.1088/0964-1726/16/6/069

Google Scholar

[11] A. Dorfmann, R.J. Ogden: Magnetoelastic modelling of elastomers, Eur. J. Mech. A/Solids 22 (2003) 497–507.

DOI: 10.1016/s0997-7538(03)00067-6

Google Scholar

[12] Y. Shen, M.F. Golnaraghi, G.R. Heppler: Experimental Research and Modeling of Magnetorheological Elastomers, Intell. Mater. Syst. Struct. 15 (2004) 27-35.

Google Scholar

[13] Polish Standard PN 78/C-01604.

Google Scholar
