Bending Modes and Magnetoelectric Effects in Asymmetric Ferromagnetic-Ferroelectric Structure

Abstract:

A model is discussed here for the resonance enhancement of magnetoelectric (ME) interactions in ferrite-piezoelectric bilayers at frequencies corresponding to bending oscillations. The thickness dependence of stress, strain and magnetic and electric fields within the sample are taken into account so that the bending deformations could be considered in an applied magnetic or electric field. The boundary conditions corresponding to bilayers that are free to vibrate at both ends, or simply supported at both ends, or fixed at one end are considered. The explicit expressions for ME voltage coefficients are derived by way of exact solution of electrostatic, magnetostatic and elasto-dynamic equations for thin plate and disk-shaped bilayers. The model is applied to a specific case of nickel and lead zinconate titanate (PZT) bilayer. Theoretical ME voltage coefficients versus frequency and PZT to nickel thickness ratio profiles are in excellent agreement with data.

• Periodical: Solid State Phenomena (Volume 190)
• Pages: 281-284
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.190.281
• Online since: June 2012
• Authors: Vladimir M. Petrov, Mirza I. Bichurin, Gopalan Srinivasan, V.M. Laletin, Roman V. Petrov
• Keywords: Bending Mode, Ferrite-Piezoelectric Bilayer, Magnetoelectric Effect, Multiferroic

References

[1] Ce-Wen Nan, M. I. Bichurin, S. Dong, D. Viehland, and G. Srinivasan, Multiferroic magnetoelectric composites: Historical perspective, status, and future directions J. Appl. Phys. 103 (2008) 031101(1-35).

DOI: 10.1063/1.2836410

[2] M. I. Bichurin, V. M. Petrov, and G. Srinivasan, Theory of low-frequency magnetoelectric coupling in magnetostrictive-piezoelectric bilayers, Phys. Rev. B 68 (2003), 054402 (1-13).

DOI: 10.1103/physrevb.68.054402

[3] S. Dong, J. Li, and D. Viehland, Ultrahigh magnetic field sensitivity in laminates of Terfenol-D and Pb(Mg1/3Nb2/3)O3–PbTiO3 crystals, Appl. Phys. Lett. 83(2003), 2265-2267.

DOI: 10.1063/1.1611276

[4] Z. Xing, S. Dong, Junyi Zhai, Li Yan, J. Li, and D. Viehland, Resonant bending mode of Terfenol-D/steel/Pb(Zr, Ti)O3 magnetoelectric laminate composites, Appl. Phys. Lett. 89 (2006), 112911(1-3).

DOI: 10.1063/1.2353819

[5] M.I. Bichurin, D.A. Fillipov, V.M. Petrov, U. Laletsin, and G. Srinivasan, Resonance magnetoelectric effects in layered magnetostrictive-piezoelectric composites Phys. Rev. B 68 (2003), 132408 (1-4).

DOI: 10.1103/physrevb.68.132408

[6] V. M. Petrov, G. Srinivasan, M. I. Bichurin, T. A. Galkina, Theory of magnetoelectric effect for bending modes in magnetostrictive-piezoelectric bilayers, J. Appl. Phys. 105 (2009) 063911(1-6).

DOI: 10.1063/1.3087766

[7] S. P. Timoshenko and D. H. Young. Vibration problems in engineering, third ed., Van Nostrand Co., New York, (1955).
