The Influence of e-Beam Irradiation on the Morphology and Functional Properties of UHMWPE

Abstract:

The paper presents an analysis of the effectiveness of radiation modification of GUR 1050 and GUR 1020 polymers intended for endoprosthesis bearing components. It has been demonstrated through extraction and expansion that the crosslinking density increases as the applied dose of electron irradiation and the molecular weight of polyethylene grow. The recorded changes were accompanied by an increase in the degree of crystallinity, which was more significant in the case of the more heavy GUR 1050 (compared to GUR 1020). The morphological changes are supported by the results of micromechanical, sclerometric and tribological examinations. Tribological examinations were documented with SEM images of the surface of specimens subjected to oscillatory friction (roll-block tester). Series of crosswise valleys and projections, arranged along the friction direction, were found on the friction surface. The smoothening of the surface and a lack of lamella fragments on the base specimens which were not subjected to e-beam irradiation are observed along with a reduction of wear due to the increasing dose of irradiation.

• Periodical: Solid State Phenomena (Volume 197)
• Pages: 6-12
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.197.6
• Online since: February 2013
• Authors: Joanna Maszybrocka, Adrian Barylski, Jerzy Cybo, Piotr Czaja
• Keywords: Crosslink Density, Crystallinity Degree, DSC, Electron Beam Irradiation, Hardness, Linear Wear, Mass Wear, SEM, UHWMPE, Young's Modulus

References

[1] A.A. Edidin, C.M. Rimnac, S.M. Kurtz, Mechanical behaviour, wear surface morphology and clinical performance of UHMWPE acetabular components after 10 years of implantation, Wear 2001 (2005) 152-158.

DOI: 10.1016/s0043-1648(01)00616-0

[2] K.W. Greer, J.V. Hamilton and E.J. Cheal, Polyethylene wear in orthopaedics, in: D.L. Wise, et al., Encyclopedic Handbook of Biomaterials and Bioengineering, Part B: Applications, Marcel Dekker Inc., New York, 2005, pp.613-638.

[3] J.G. Lancaster, D. Dawson, G.H. Isaac, The wear of ultra-high molecular weight polyethylene sliding on metallic and ceramic counterfaces representative of current femoral surfaces in joint replacement, Proc. Inst. Mech. Eng. 21 (1997) 17-24.

DOI: 10.1243/0954411971534647

[4] M. Ohta, S.H. Hyon, S. Tsutumi, Control of crystalline orientation to enhance the wear resistance of ultra-high molecular weight polyethylene crystallization cups for artificial joints. Wear 255 (2003) 1045–1050.

DOI: 10.1016/s0043-1648(03)00284-9

[5] H. Marrs, D.C. Barton, C. Doyle, R.A. Jones, E.L.V. Lewis, I.M. Ward, J. Fischer, The effect of molecular orientation and acetylene-enhanced crosslinking on the wear of UHMWPE in total artificial joints, J. Mat. Sci. Mater. Med. 12 (2001) 621-628.

[6] J. Maszybrocka, J. Cybo, J. Frąckowiak, Change of micromechanical properties of polyethylene induced by a tribological process in polymer/metal system, Mat. Sci. Forum 513 (2006) 75-85.

DOI: 10.4028/www.scientific.net/msf.513.75

[7] J. Cybo, J. Maszybrocka, A. Barylski, J. Kansy, Resistance of UHMWPE to plastic deformation and wear and the possibility of its enhancement through modification by radiation, J. Appl. Polym. Sci. 125 (2012) 4188-4196.

DOI: 10.1002/app.36573

[8] J. Cybo, J. Maszybrocka, P. Duda, Z. Bartczak, A. Barylski, S. Kaptacz, Properties of ultra high molecular weight polyethylene with structure modified by plastic deformation and electron-beam irradiation, J. Appl. Polym. Sci. 125 (2012) 4197-4208.

DOI: 10.1002/app.36572

[9] D.S. Li, H. Garmestani, S. Ahzi, et. al, Microstructure Design to Improve Wear Resistance in Bioimplant UHMWPE Materials, J. Eng. Mater. Technol. 131 (2009) 0412111 (7 pages).

DOI: 10.1115/1.3183786

[10] F. Addiego, O. Buchheit, D. Ruch, S. Ahzi, A. Dahoun, Does Texturing of UHMWPE Increase Strength and Toughness? A. Clin. Orthop. Relat. Res. 469 (2011) 2318-2326.

DOI: 10.1007/s11999-010-1716-7

[11] ISO 7206 (1996): Implants for surgery – Partial and total hip joint prostheses.

[12] P. J Flory, Principles of Polymer Chemistry, Cornell Unversity Press, New York, (1953).
