Application of Vibration for Energy and Data Transfer in Mechanical Constructions; Energy Harvesting

Abstract:

The work presents a method of at once power and information transmission through pair of rails using SURPS (Smart Ultrasonic Resonant Power System). The solution allows to (electrically) feed sensors located in hardly accessible places of mechanical constructions with simultaneous half-duplex data transmission (e.g. measurement “question-response”), when conventional power supply (requiring e.g. electricity networks, storage batteries, batteries, etc.) is eliminated. The mechanism of power transmission consists in “sending” of mechanical energy through an actuator in a form of “pure” sinusoidal ultrasonic wave and next “receiving” it and transforming into useful electrical current by a harvester. Both magnetostrictive and piezoelectric harvesters/actuators were used. For information transfer F2F (frequency - double frequency) procedures were used, they are a kind of FM (Frequency Modulation). To optimise transmission (the highest possible efficiency and acceptably low noise level), software allowing to select the right type of an actuator, modulation and the recommended frequency band was developed. Additionally it is possible to determine resonance frequency for each construction which is to be used for information and power transfer.

• Periodical: Solid State Phenomena (Volume 224)
• Pages: 249-254
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.224.249
• Online since: November 2014
• Authors: Jerzy Kaleta, Daniel Lewandowski*, Przemysław Wiewiórski
• Keywords: Energy Harvesting, Magnetostrictive/Piezoelectric Transducer, Power, Simultaneous Transmission of Data, Simultaneous Transmission of Power, Solid Bars, Ultrasonic System, Wireless Sensors

References

[1] J. Kaleta, Materiały magnetyczne Smart. Budowa, wytwarzanie, badanie właściwości, zastosowanie. Oficyna Wydawnicza Politechniki Wrocławskiej, Wrocław, (2013).

[2] T.J. Lawry, K.R. Wilt, J.D. Ashdown, H.A. Scarton, G.J. Saulnier, A high-performance ultrasonic system for the simultaneous transmission of data and power through solid metal barriers. Ultrasonics, , IEEE Transactions on, 60(1), 194-203.

DOI: 10.1109/tuffc.2013.2550

[3] J. Kaleta, K. Kot, R. Mech, P. Wiewiórski, High power actuator based on magnetostrictive composite core with temperature drift compensation. Key Engineering Materials (2014), vol. 598, s. 69-74.

DOI: 10.4028/www.scientific.net/kem.598.69

[4] J. Kaleta, K. Kot, R. Mech, P. Wiewiórski, The use of magnetostrictive cores for the vibrations generation and energy harvesting from vibration in the selected frequencies of work. Key Engineering Materials. (2014), vol. 598, s. 75-80.

DOI: 10.4028/www.scientific.net/kem.598.75

[5] J. Kaleta, R. Mech, P. Wiewiórski, High power interactive actuator system based on magnetostrictive composite core. IRF 2013, Funchal, Portugal, 23-27 June (2013).

[6] J. Kaleta, P. Wiewiórski, Rapid demagnetization of neodymium magnets, due to mechanical shock, as a pulse power supply for microprocessor system. IRF 2013, Funchal, Portugal, 23-27 June (2013).
