Experimental Determination of Crack Driving Forces for Small Cracks

Abstract:

The crack tip field of small fatigue cracks was measured using digital image correlation DIC. For this purpose, smooth specimen were fatigued until a certain amount of damage was visible on the surface. This specimens were then placed in a micro-tensile device in the SEM. The grey value patterns obtained at two different load levels were analyzed with DIC. Fitting the Williams series for the crack tip field to the corresponding DIC-displacement field in the crack tip area yielded the mode-I, and the mode-II stress intensity factors together with the T-stresses. It was found that the experimental values of the stress intensity factor were comparatively high with pronounced mode-II contributions.

You might also be interested in these eBooks

Materials Structure & Micromechanics of Fracture VIII

View Preview

Info:

Periodical:

Solid State Phenomena (Volume 258)

Pages:

495-500

DOI:

https://doi.org/10.4028/www.scientific.net/SSP.258.495

Citation:

Cite this paper

Online since:

December 2016

Authors:

Angelika Brueckner-Foit*, Pascal Pitz, Phillip Grahlmann, Frank Zeismann

Keywords:

Crack Tip Field, Digital Image Correlation, Small Cracks, Stress Intensity Factor

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] McNeill, S.R., Peters, W.H., Sutton, M.A., Estimation of stress intensity factor by digital image correlation, Engineering Fracture Mechanics Vol. 28 (1987) 101 – 112.

DOI: 10.1016/0013-7944(87)90124-x

Google Scholar

[2] J. Rethore and et. al., Estimation of mixed-mode stress intensity factors using digital image correlation and an interaction integral, International Journal of Fracture, Vol. 132 (2005) 65 – 79.

DOI: 10.1007/s10704-004-8141-4

Google Scholar

[3] S. Roux, J. Rethore and F. Hild, Digital image correlation and fracture: an advanced technique for estimating stress intensity factors of 2D and 3D cracks, Journal of Physics D: Applied Physics, Vol. 42 (2009), 21.

DOI: 10.1088/0022-3727/42/21/214004

Google Scholar

[4] M. Zanganeh, Experimental investigation of crack paths, Mechanical Engineering Department, University of Sheffield, (2008).

Google Scholar

[5] T. L. Anderson, Fracture Mechanics - Fundamentals and Applications, 3rd edition, CRC Press, (2005).

Google Scholar
