Effect of Membrane Forces on Punching Shear Capacity of Flat Slabs

Abstract:

The paper presents the analysis of the membrane forces and moment redistribution effect on punching shear capacity of flat slabs on the area of the inner column. The previous experimental tests performed on the isolated slab specimens representing the slab-column connections are assessed by the method that uses the levels-of-approximation (LoA) approach, introduced in the fib Model Code 2010. LoA I to III are intended for design and the highest LoA IV, which uses non-linear finite element analysis (NLFEA) combined with the Critical Shear Crack Theory (CSCT) model is used for assessment and a better understanding of the punching shear phenomenon. Both, multi-layered (2D) shell and three-dimensional (3D) continuum elements were used to model the slab-column connection specimen and were found to accurately predict the structural response. The numerical model was then used to conduct a parametric study on the influence of slab continuity on punching shear resistance. The results from a non-linear analysis of continuous slab models are then compared with the punching shear resistance obtained from the code provisions. The paper will present the obtained results by the LoA method and recommendations concerning of NLFEA modelling of RC flat slabs.

• Periodical: Solid State Phenomena (Volume 322)
• Pages: 136-141
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.322.136
• Online since: August 2021
• Authors: Aleksandar Vidaković, Lucia Majtánová, Jaroslav Halvonik*
• Keywords: Compressive Membrane Action, Continuous Slab, Flat Slabs, Levels-of-Approximation Approach, Non-Linear Analysis, Punching Shear

References

[1] J. Einpaul, M. Fernández Ruiz, A. Muttoni, Influence of moment redistribution and compressive membrane action on punching strength of flat slabs, Engineering Structures. Vol. 86 (2015), 43-57.

DOI: 10.1016/j.engstruct.2014.12.032

[2] fib Model Code for Concrete Structures 2010, Lausanne: International Federation for Structural Concrete, Germany (2013), 434p.

[3] A. Muttoni, Punching shear strength of reinforced concrete slabs without transverse reinforcement, ACI Struct. J. 105 (2008), 440-50.

DOI: 10.14359/19858

[4] J. Halvonik, L. Majtánová, Experimental investigation of the maximum punching resistance of slab-column connections, Slovak Journal of Civil Engineering. Vol. 26 (2018), 22-28.

DOI: 10.2478/sjce-2018-0017

[5] SOFiSTiK AG, ASE – General Static Analysis of FE Structures, Oberschleissheim (2020).

[6] V. Červenka, L. Jendele and J. Červenka, ATENA Program Documentation, Prague (2020).

[7] L. Kadlec, V. Červenka, Uncertainty of numerical models for punching resistance of RC slabs, fib Symposium Copenhagen, Denmark (2015).

[8] Eurocode 2, Design of concrete structures – Part 1-1: General rules and rules for buildings.
