Measurement of Natural Properties of a Beam Based on Machine Vision

Abstract:

The natural properties of flexible beam is measured by using machine vision in which the image of vibrate flexible Beam is acquired continuously. Different from the previous contact measurement methods, the binary processing method and centroid method is utilized to binarize the image and extracts the position of marked point. Gathering and calculating the position information preprocessed in MATLAB indicates the natural properties of flexible beam. Furthermore, the test results compared with the theoretical analysis verifies the validity of the proposed method.

• Periodical: Advanced Engineering Forum (Volumes 2-3)
• Pages: 162-166
• DOI: https://doi.org/10.4028/www.scientific.net/AEF.2-3.162
• Online since: December 2011
• Authors: Qing Peng Han, Pei Xin Gao, Ling Tang, Xiao Wei Sun, Zhong Luo
• Keywords: Flexible Beam, Machine Vision, Natural Property

References

[1] J Lin Burn, Vibration Tolerance in Optical Imaging [J]. Optical Engineering, March, 1993, 32(3).

[2] T C Chu, et al. Applications of Digital Image Correlation Techniques to Experimental Mechanics [J]. Experimental Mechanics, September, 1985, 25(3).

[3] Kaoli Huang, Changqing Zhu, Application of Liner CCD Sensor. Proceedings of the International Symposium on Test and Measurement, 1999: 951-953.

[4] Long Qi. The Experiment of Testing Object Vibration by the Linear Array CCD, Laboratory Science, 2006(in Chinese).

[5] Bo Jin. The Research of Bridge Detection and Optic Testing Methods [D], Tianjin: Tianjin university department of solid force, 20049(in Chinese).

[6] Tuoqun Liu. A Non-contact Vibration Measurement Method Based on CCD. Machinery & Electronics, 2002, (4): 76～77(in Chinese).

[7] The Specification of Daheng Image Vision Technology, China Daheng Group Inc.
