Vibration Suppression of a 3-DOF Parallel Manipulator Based on Hybrid Negative Impulses Multi-Mode Input Shaping

Abstract:

The classic multi-mode negative impulses input shapers can suppress the residual vibration of the multi-mode system effectively. But when these several frequencies bandwidths and amplitudes of vibration modes are greatly different, the time delay and the suppression performances of input shapers are decreased. However, the hybrid multi-mode negative impulses input shapers can overcome the disadvantage. The hybrid double-mode negative impulses input shapers of a 3-DOF parallel manipulator and are constructed and compared with the classic multi-mode negative impulses input shapers. And the numerical simulations are shown out, for different frequencies bandwidths and amplitudes of vibration, and the hybrid multi-mode negative impulses input shapers can increase the total suppression performance of input shaper.

• Periodical: Advanced Engineering Forum (Volumes 2-3)
• Pages: 372-377
• DOI: https://doi.org/10.4028/www.scientific.net/AEF.2-3.372
• Online since: December 2011
• Authors: Yan Yan Han, Bing Li, Yu Lan Wei, Shou Xin Zhu, Ying Jun Dai
• Keywords: Hybrid Input Shaping, Multiple-Mode, Negative Impulses, Residual Vibration

References

[1] W. E. Singhose, W. P. Seering and N. C. Singer: Time-optimal negative input shapers, Journal of Dynamic, Measurement, and Control, 119(1997), p.198.

DOI: 10.1115/1.2801233

[2] Youef-Toumia Kamal and Osamuito: A Time Delay Controller for Systems with Unknown Dynamics, ASME Journal of Dynamic Systems, 112(1990), p.133.

[3] Z. Mohamed, A. K. Chee and A. W. I. Mohd-Hashim, et al: Techniques for vibration control of a flexible robot Manipulator, J. Robotica, 24(2006), p.499.

DOI: 10.1017/s0263574705002511

[4] B. Li, X. P. Zhang and J. K. Mills: Vibration Suppression of a 3-PRR Flexible Parallel Manipulator Using Input Shaping, C. IEEE International Conference on Mechatronics and Automation, Changchun, China, 2009, p.3539.

DOI: 10.1109/icma.2009.5246204

[5] M. D. Baumgart and L. Y. Pao: Discrete time-optimal command shaping, J. Automatica, 43(2007), p.1403.

DOI: 10.1016/j.automatica.2007.01.003

[6] F. D. Mohammed and N. M. Ziyad: Nonlinear Input - shaping Controller for Quay-side Container Cranes, J. Nonlinear Dynamics, 45(2006), p.149.

DOI: 10.1007/s11071-006-2425-3

[7] B. Li, L. Y. Xie and Y. L. Wei: Vibration Suppression Based on Negative Impuses Input Shaping for a 3-DOF Parallel Manipulator, Journal of Northeastern University (Natural Science), 10(2010), p.1479.

[8] B. Li, L. Y. Xie and Y. L. Wei: Vibration Reduction of Flexible System by Time-Optimal Multi-mode Input Shaper, Journal of Northeastern University (Natural Science), 9(2010), p.1337.

[9] N. C. Singer, L. Y. Pao and W. E. Singhose: An Effcient Algo-rithm for the Generation of Multiple - Mode Input Shaping Sequences, IEEE International Conference on Control Applic-ations, Dearborn, MI, 1996, p.373.

DOI: 10.1109/cca.1996.558811

[10] X. P. Zhang, J. K Mills and W. L. Cleghorn: Dynamic modeling and experimental validation of a 3 PRR parallel manipulator with flexible intermediate links, Journal of Intelligent and Robotic Systems, 50(2007), p.323.

DOI: 10.1007/s10846-007-9167-4
