Tracking Testing of Dynamic Errors for Linear Guideway Based on Position Sensitive Detector

Abstract:

The dynamic precision of linear guideway is very important performance for mechatronic equipments. The dynamic errors for the linear guideway of machine tools can reduce machining precision. In according with the advantage of high-speed response, high detection accuracy and non-contact measurement, position sensitive detector (PSD) is widely used in industrial dynamic measurement. In this paper an approach for measuring the motion stability based on PSD is proposed. The measurement system based on PSD is designed and the measurement errors are analyzed. The measurement results show the approach can measure accurately the motion stability of guideway in two dimensions with features of high precision.

By email View Pdf

You have full access to the following eBook

Read eBook

Info:

Periodical:

Advanced Engineering Forum (Volumes 2-3)

Pages:

362-365

DOI:

https://doi.org/10.4028/www.scientific.net/AEF.2-3.362

Citation:

Cite this paper

Online since:

December 2011

Authors:

Da Zhong Guo, Yuan Yuan Zou, Si Jun Zhu, Ming Yang Zhao

Keywords:

Laser Tracing Measurement System, Motion Stability Measurement, Position Sensitive Detector (PSD)

Export:

RIS, BibTeX

Permissions:

Creative Commons CC BY 4.0

Citation:

References

[1] Huang Xin. Research on Engineering and Analysis on Performance of Linear Rolling guide. Beijing: Higher Education Press, 2004. 3-21.

Google Scholar

[2] Zhang Daxing, Jia Wei, Guan Bolin, Investigation for vibration measurement and control based on photoelectric displacement detectional, Journal of Electronic Measurement and Instrument, 2009, 23, 163-166.

Google Scholar

[3] Su Haiyan, Luo Zushun, Yang Yongcai, The Study of Photoelectric Online Measurement for Axial Vibration Based on LabVIEW, Chinese Journal of Scientfic Instrument, 2004, 25, 26-28.

Google Scholar

[4] Guo Lifeng, Zhang Guoxiong, Gong Qiang, Zheng Qi, Application of 2-D Position Sensitive Detector in Spatial Straightness Measurement of Guide Rail, Transactions of Tranjin University, 2005, 11(1), 44-48.

Google Scholar

[5] Chen Dongyan, Lin Bin, Chen Yuqing, Development and Progressing of Position Sensitive Detector, Optical Instruments, 2004, 26(4), 68-71.

Google Scholar

[6] Zhu Mingzhu, Chen Peifeng, Zhou Baoyu, Zeng Wei, The Error Analysis and Experimental Study on PSD Used in Laser Position Detection, Optoelectronic Technology & Information, 2006, 19(3), 10-14.

Google Scholar
