Design and Analysis of a Novel Wall-Climbing Robot Mechanism

Abstract:

A novel wall-climbing robot mechanism designed for anti-hijacking task is presented. This mechanism consists of a negative pressure adhesion module, a vacuum suction module and a planetary-gear train. The design of biped-wheel hybrid locomotion mechanism, with the advantages of wheeled robots and legged robots, allows the robot to move fast and cross over obstacles easily. This design qualifies the robot for the motion of moving straight, turning in plane and crossing between inclined surfaces. Then the kinematics equations are derived and the locomotion modes are analyzed. Many experiments have been implemented and the results prove that the robot has such characteristics as rapid speed, excellent transition ability between inclined surfaces and curved surface adaptability. Therefore, this novel wall-climbing mechanism could be used for the application of inspection, surveillance and reconnaissance.

• Periodical: Advanced Engineering Forum (Volumes 2-3)
• Pages: 346-351
• DOI: https://doi.org/10.4028/www.scientific.net/AEF.2-3.346
• Online since: December 2011
• Authors: Wei Guang Dong, Hong Guang Wang, Ai Hua Liu, Zhen Hui Li
• Keywords: Hybrid Locomotion, Kinematics, Wall-Climbing Mechanism
