Nonlinear Dynamic Behavior of Double-Disk Isotropic Rotor System with Axial Rub-Impact

Abstract:

In the case of considering the shear effect and gyroscopic effect, a finite element model is developed to study the nonlinear dynamic behavior of a double-disk isotropic rotor- bearing system with axial rub-impact in this paper. The influences of rotational speed and initial phase difference on the operation stability of the rotor-bearing system are discussed. It transpires that the response of the rotor system with axial rub- impact is mainly synchronous periodic motion. The vibration signals of axial rub-impact include such as the synchronous signal and the multiple frequencies, in which the synchronous signal is dominating signal. There is no weakening wave phenomenon in time wave plot. All the results are in reasonable good agreement with those observed in engineering. The results of this paper could provide certain reference for fault diagnosis and self-healing of large high-speed rotating machinery system, thus ensuring the safe operation of the system.

• Periodical: Advanced Engineering Forum (Volumes 2-3)
• Pages: 678-682
• DOI: https://doi.org/10.4028/www.scientific.net/AEF.2-3.678
• Online since: December 2011
• Authors: Y. Zhang, W.M. Wang, J.F. Yao
• Keywords: Axial Rub, Finite Element Method (FEM), Impact, Nonlinear Dynamic Behavior, Rotor-Bearing System

References

[1] Wen Bangchun，Wu Xinhua, Ding Qian etc. The theory and experiment of the nonlinear dynamic mechanics of rotating machinery, Beijing: Science press, 2004.

[2] Huang Wenhu, Xia Songbo, Jiao Yinghou etc. The basic theory and method of the nonlinear dynamic mechanics design of rotating machinery, Beijing: Science press, (2004).

[3] Yu Lie, Liu Heng, Dynamic mechanics of rotor-bearing system, Xian: Xian Jiaotong University press, (2001).

[4] Li Chaofeng, Li XiaoFeng, Ma Hui etc., The nonlinear dynamic behavior of a rotor-bearing system with rub-impact by a continuous model, Journal of Vibration Engineering. 22(2009) 395-399.

[5] Ding Qian, Lateral Vibration of a Rotor/Bearing System with Axial Rubs, Journal of Mechanical Strength. 26(2004) 132-137.

[6] Zhenwei Yuan, Fulei Chu, Rujiang Hao, Simulation of rotor's axial rub-impact in full degrees of freedom, Mechanism and Machine Theory. 42(2007)763-775.

DOI: 10.1016/j.mechmachtheory.2006.07.001

[7] Xu Kejun, Qin Haiqin, Numerical Simulation Analysis For Rubbing Model of A Two-Disk Rotor-Stator System, Journal of Vibration and Shock. 26（2007）74-79.

[8] Xu Kejun, Qin Haiqin, Dynamic Model of Two Disk Rotor-Stator Rubbing Action, Journal of Vibration and Shock. 26（2007）17-21.
