A Three Dimensional Virtual System Used to Analyze the Normal and Prosthetic Joint of the Hip

Abstract:

Treatment of hip pathology has evolved over the last two centuries, ranging from rudimentary surgical procedures to modern hip arthroplasty, with an explosion marked in the last 30 years, considered to be one of the most successful surgeries to date. Hip arthroplasty is a permanent challenge due to the desire to discover the "supreme prosthesis", for which competition is still open. Hip disorders requiring prosthesis show a change in articular morphology. Among the most common medical conditions that have as final therapeutic solution hip arthroplasty are: coxarthrosis, both primary and secondary, followed by traumatic conditions: femoral neck collapse and femoral neck pseudarthrosis, aseptic head necrosis femoral stage III, as well as rheumatic coxitis from rheumatoid arthritis, ankylosing spondylitis or juvenile art. Endoprosthetic arthroplasty can be defined as an intervention of reconstructive surgery with bone sacrifice and prosthetic replacement of the articular components. It is, in the end, an operation aimed at restoring joint mobility and normal functioning of the muscles, ligaments and other periarticular structures that control joint movement. The materials initially used (glass, metal, plastic) did not have the desired bone strength and integration capacity. It followed the development of cemented implants, obtaining different types of cement with better and better quality. Problems arising from cemented arthroplasty (decimation, involving prosthetic revision) have led to a parallel development of the design and materials used for uncured prostheses with the possibility of very good integration of prosthetic material into the bone, raising them to the top of preferences in recent years. Treatment of hip pathology has evolved over the last two centuries, ranging from rudimentary surgical procedures to modern hip arthroplasty, with an explosion marked in the last 30 years, considered to be one of the most successful surgeries to date. The purpose of this study was to obtain the three-dimensional models of the hip joint and the prosthesis for the use of these models for various analyzes and virtual experiments. At the end of the paper important conclusions were drawn based on the results obtained in the simulations using the finite element method.

• Periodical: Advanced Engineering Forum (Volume 34)
• Pages: 165-174
• DOI: https://doi.org/10.4028/www.scientific.net/AEF.34.165
• Online since: October 2019
• Authors: Razvan Cristian Vaduva, Ilaria Lorena Petrovici, Mihai Catalin Tenovici, Danut Nicolae Tarnita, Dragos Laurentiu Popa*, Otilia Rogoveanu, Bogdan Capitanescu
• Keywords: CT Image, FEA Simulation, Software Methods, Virtual Bones, Virtual Prosthesis

References

[1] L. D. Anderson, W. R. Hamsa, T. L. Waring, Femoral head protheses, J. Bone Joint Surg., , 46A, (1964) 1049-1065.

[2] N. S.Eftekhar, Status of femoral head replacement in treating fracture of femoral neck. Hemiarthroplasty versus toal prothesis, Orthop. Rev., 2, (1973) 15-23.

[3] A. Lortat-Jacob, P. H.,Videcoq, P. H. Hardy, D. Fontes, B. de Somer, J. Benoid, La prothese Intermediare dabs las fractures du col du femur, Rev. Chir. Orthop., 78, (1992) 191-200.

[4] J. C. De Lee, Fractures and dislocation of the hip in Rockwood and Green's, Fractures in Adults, Ed. Lippincott-Raven, Philadelphia, U.S.A., (1990).

[5] R.A. Balderston, The Hip, Philadelphia, London (1992) 358-416.

[6] S. Netter, Concise orthopaedic anatomy, second edition, Elsevier Inc, (2010) 252-268.

[7] D. Popa, D. Tarnita, I. Iordachita, Study method for human knee applicable to humanoid robots, The 14th International Workshop on Robotics in Alpe-Adria-Danube Region, RAAD, vol.5, (2005) 26-28.

DOI: 10.1109/raad.2010.5524565

[8] D.L. Popa, G. Buciu, D .Grecu, D. Niculescu, L. Chiutu, M. Stoica, Studies about virtual behavior of tibia fractures and nails during the fixation process, JIDEG, no.8, (2013) 5-10.

[9] D. Tarnita, D.N. Tarnita, N. Bizdoaca, D. Popa, Contributions on the dynamic simulation of the virtual model of the human knee joint, Materialwissenschaft und Werkstofftechnik: Entwicklung, Fertigung, Prüfung, Eigenschaften und Anwendungen technischer Werkstoffe, vol. 40, no. 1-2, (2009) 73-81.

DOI: 10.1002/mawe.200800375

[10] D.L. Popa, A. Duta, D. Tutunea, G. Gherghina, G. Buciu, D. C. Calin, Virtual Methods Applied to Human Bones and Joints Re-Construction Used for Orthopedic Systems, Applied Mechanics and Materials, vol. 822, (2016) 160-165.

DOI: 10.4028/www.scientific.net/amm.822.160

[11] D. Popa, D.N. Tarnita, D. Tarnita, D. Grecu, The generation of the three-dimensional model of the human knee joint, Romanian Journal of Morphology and embryology, vol.46 no.4, (2005) 3-6.

[12] D. Tarnita, D. Popa, D. N. Tarnita, D. Grecu, CAD method for 3D model of the tibia bone and study of stresses using the finite element method, Rom J Morphol Embryol, ISSN 1220-0522, Vol. 47. No.2, (2006) 181-186.

[13] G. Buciu, D.L. Popa, D. Grecu, D. Niculescu, R. Nemes, Virtual comparative study on the use of nails at the fixation of tibial fractures using finite element method, Proceedings of The 4th International Conference ²Advanced Composite Materials Engineering ² COMAT 2012 Brasov Romania, Lux Libris Publishing House, (2012) 381-386.

[14] M. Vătu, M.M. Crăițoiu, D. Vintilă, V. Mercuț, M.S. Popescu, M. Scrieciu, L.D. Popa, Determination of resistance forces from mandibular movements through dynamic simulation using kinematic analysis and finite elements method, Romanian Journal of Oral Rehabilitation, Vol. 10 Issue: 1 (2018) pp.20-28.

[15] M. Vatu,. D. Vintila, D.L. Popa, 3D Skull Virtual Model Based on CT or MRI Images Used for Dentistry Simulations, Applied Mechanics and Materials, Vol. 880, (2018) 101-110.

DOI: 10.4028/www.scientific.net/amm.880.101

[16] A.D. Popa, A.M. Mogosanu, D.L. Popa, A. Duta, A. Teodorescu, Virtual and rapid prototyping methods applied in civil engineering: Snow, wind and earthquake simulations on a five storey building, FME Transactions, vol. 45, no. 2, (2017) 276-282.

DOI: 10.5937/fmet1702276p
