Evaluation of Dynamic Property of Radiogram under Repetitive Drop Shock

Abstract:

Repetitive impact during highway and railway transportation has potential and severe harm for the product with fragile or damageable component. The radiogram belongs to a typical electronic product with panel and box structure, and occurs with the falling down of loudspeaker contacted on the top box, the failure of electronic components, and the fracture of outside box during transportation and storage. So the main feature of this article is the analysis on the natural vibration property, and the evaluation on the drop shock property including amplification factor and relevant curves under nine kinds of repetitive impact with different impact duration and drop height. The results show that the amplification factor markedly rise while the impact duration 2.02ms (nearly causing the resonance of radiogram), the repetitive drop shock may bring more serious damage than single impact load, so the case should be paid attention for the design of package cushioning.

• Periodical: Applied Mechanics and Materials (Volumes 101-102)
• Pages: 1087-1091
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.101-102.1087
• Online since: September 2011
• Authors: Yan Feng Guo, Yan Hong Mao, Yun Gang Fu, Wen Cai Xu
• Keywords: Amplification Factor (AF), Natural Frequency, Radiogram, Repetitive Drop Shock

References

[1] A.M. Veprik: Journal of Sound and Vibration, Vol. 259 (2003) No. 1, p.161–175.

[2] C.M. Harris, C.E. Crede and M.T. Hatae: Shock and vibration handbook, packaging design (McGraw-Hill Book Inc., New York 1996).

[3] G.J. Burgess: Journal of Testing and Evaluation, Vol. 28 (2000) No. 2, pp.116-120.

[4] B. Song: Packaging Engineering, Vol. 17 (1996) No. 2, pp.1-5. (In Chinese).

[5] M. Xiang and R. Eschke: Packaging Technology and Science, Vol. 17 (2004) No. 1, pp.31-35.

[6] L. Lu: Packaging Engineering, Vol. 26 (2005) No. 6, pp.1-4. (In Chinese).

[7] Z. Wang and J. Jiang: Packaging Technology and Science, Vol. 23 (2010) No. 4, pp.227-238.

[8] L. Wen, X. Fu, J. Zhou, Q. Wang and J. Lee: ICEPT-HDP 2008 (Shanghai, China, Jul. 28-31, 2008), pp.1-7.

[9] J.J.M. Zaa, W.D. Driel, H.P. Hochstenbachl and G.Q. Zhang: Microelectronics Reliability, Vol. 49 (2009) No. 8, pp.846-852.

[10] R.D. Mindlin: Bell System Technical Journal, Vol. 24 (1945) No. 7-10, pp.353-461.
