Special Honing Machine for Cylinder Internal Hole

Abstract:

The special honing machine is used in the precision machine of the monomer hydraulic prop cylinder internal hole surface. The main revolving movement is driven by motor, the reciprocating linear motion is actuated by hydraulic ram. Honing machine consists of three parts, mechanism, the hydraulic system and the electric control system. The work principle and the processing process, the interlock relation between movements and the straight line feed motion velocity modulation method of this machine were discussed in this study. The special honing machine designed for the monomer hydraulic prop cylinder is convenient and easy for person to operate, and has high efficiency. The reciprocating linear motion driven by hydraulic ram is steady when direction is changed. It is convenient to change speed, and has advantageous of enhancement processing surface quality.

• Periodical: Applied Mechanics and Materials (Volumes 101-102)
• Pages: 33-36
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.101-102.33
• Online since: September 2011
• Authors: Guang Zhen Cheng, Xu Qin Chen
• Keywords: Cylinder, Honing Machine, Maintenance

References

[1] R.Y. Ming and T.F. Yin: Hydraulic and pneumatic, Vol. 182(2006) No. 10, pp.64-66 (in Chinese).

[2] G. Z. Cheng and Y. B. Cheng: Advanced Materials Research. Vols. 201-203 (2011), pp.2338-2342.

[3] H.J. Zhang: Hydraulic metal cutting machine tools (Jiangsu Science and Technology Press, China 2009) (in Chinese).

[4] Y.S. Fan. Electrical Control and PLC applications (China Electric Power Press, China 2006) (in Chinese).

[5] S.H. Chen: Machinery equipment electrical control (South China University Press, China 2002) (in Chinese).

[6] Z.Q. Qi: Machine Electrical Control Technology (Machinery Industry Press, China 2002)(in Chinese).
