Analysis on Overturning of Single Pier Bridge and Reinforcement Design Method

Abstract:

With the lesson from the overturning accident of single-pier bridge and based on the analysis on the size and distribution mode of the load on the bridge surface when the ramp bridge of Tianjin segment in the Jin-Jin Expressway collapsed, this Article drafts the load size and distribution mode are (possibly undertaking up to 4x165t load) studied out for analysis and design of single pier bridge of pier-girder consolidation for the analysis on the calculation of the overturning resistance for single-column girder, and analyzes the overturning resistance capacity of single-column girder with pier-girder consolidation according the planned load size and distribution mode. In addition, this Article proposes the reinforcement measures by adding the column supports at the horizontal direction of the single-column pier, thus effectively improving the overturning resistance capacity of main girder. This Article may be used as the reference for the study of overturning resistance and the reinforcement of single-column pier bridge.

• Periodical: Applied Mechanics and Materials (Volumes 105-107)
• Pages: 1338-1341
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.105-107.1338
• Online since: September 2011
• Authors: Guo Yong Huang, Chang Qing Lan, Xu Lan
• Keywords: Overturning Resistance, Partial Compression, Reinforcement, Torsion

References

[1] L.C. Fan: Seismic Resistance of the Bridges [M] (Tongji University Press, China 1997)(In Chinese)

[2] X.Y. Cheng: Analysis on Horizontal Interior Force of Single-Chamber Box Girder and the Width of Load Distribution [J], Journal of Chongqing Jiaotong University(In Chinese)

[3] Z.H. Chen, G.S. Wu and X.D. Sun: Mechanic Characteristics of Continuous Girder Structure with Single-Column Girder [J], Journal of Highway and Transportation Research and Development, 2006, 23(6), pp.89-91(In Chinese)

[4] Ministry of Transport of the People's Republic of China: JTG D62-2004 Code for Design of Highway Reinforced Concrete and Prestressed Concrete Bridges and Culverts [S] (China Communications Press, China 2004)(In Chinese)

[5] S.Z. Yuan, G.L. Dai and J.W. Wu: Discussion on the Stability from Horizontal Overturning of the Bridge with Single-Column and Wide-Amplitude Continuous Girder [J], Chinese and Overseas Architecture, 2008 (7)(In Chinese)

[6] X.M. Qian: Study on the Overturn Resistance of Ramp Bridge with Single-Column Pier [J], Value Engineering(In Chinese)
