Experimental Study of Angular Acceleration Sensor and its Error Analysis

Abstract:

For shaft angular acceleration is the key to rotary system state inspection and fault analysis, two new angular acceleration sensors based on the principle of electromagnetic induction are presented. When the angular acceleration component exist in rotary system, this component is output in the form of induced potential through electromagnetic coupling. The output voltage of sensor can reflect the changes of mechanical angular acceleration according to the experiment. The errors of sensor on actual working condition are analysed, and a new calibration method of sensor is presented, which affords technical support for the popularization and application of sensor.

• Periodical: Applied Mechanics and Materials (Volumes 105-107)
• Pages: 1930-1935
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.105-107.1930
• Online since: September 2011
• Authors: Hao Feng, Hao Zhao, Li Jun Ding
• Keywords: Angular Acceleration, Asynchronous Motor, Calibration, Error Analysis, Excitation

References

[1] Schubert P J. Vehicle rollover sensing using angular accelerometer[P].US: No.20050113983(A1).

[2] Y.F. Zhang, C.W. Chen and F.L. Deng . Study on large sector maneuvering launch for tactical missile. Aerospace Control, Vol. 22 (2004) No.2, p.19. In Chinese.

[3] Q.M. Wei, J.H. Yuan, B.H. Zhang, Z. LI. A novel attitude control technology of micro-satellite. Space Electronic Technology, (1993) No.3, p.59. In Chinese.

[4] T.L. Zhang. The application of piezoelectric angular accelerometer in swivel table control. Techniques of Automation and Applications, Vol. 19 (2000) No.5, p.24. In Chinese.

[5] Gola A, Chiesa E. Interface for MEMS-based rotational accelerometer for HDD applications with 2.5 rad/s2 resolution and digital output. IEEE Sensors Journal, Vol. 3 (2003) No.4, p.383.

DOI: 10.1109/jsen.2003.815785

[6] Godler I, Akahane A, 0hnishi K, et a1. A Novel Rotary Acceleration sensor. IEEE control System Magazine, Vol. 15 (1995) No.1, p.56.

[7] M. Zhou, X.R. Wu and F. Hong. Study of a new style of angular accelerometer. Aerospace Control, (1999) No.2, p.51. In Chinese.

[8] F.X. Zhang : Piezoelectric crystal force and acceleration sensor (Sichuan science and Tech Publications, China 1995), P.311-325.

[9] X.Z. Chi, H,Z. Jin and J.S. Wang. Research on force balanced angle accelerometer. Chinese Journal of Scientific Instrument, Vol. 24 (2003) No.4, p.23. In Chinese.

[10] X.S. Wu, W.Y. Chen. Review on angular accelerometer development. Journal of Chinese Inertial technology, Vol. 15 (2007) No.4, p.458. In Chinese.
