Dynamic Elasto-Plastic Analysis on the Steel Arch Truss under Earthquake Action

Abstract:

In this paper, the elasto-plastic dynamic analysis on the steel spatial arch truss with 120m span and 0.1 rise-span ratio is carried out under with SAP2000. The plasticity development level and failure mode of the structure are estimated by the method of increasing the peak acceleration gradually and the plastic hinge theory. The results show that the structure displacement response changed nonlinearly with the increased peak acceleration of the earthquake; Its critical peak acceleration of EL earthquake wave when applied in horizontal direction is 222gal, and is 274gal when applied in vertical direction; The ratio of its maximal node horizontal and its structural height is 1/783 when EL-Centro waves applied on structure in horizontal direction; The ratio of its maximal node vertical and its structural span is 1/751, when EL-Centro waves applied in vertical direction; The failure mode of the truss under the earthquake action is elasto-plastic dynamic buckling.

• Periodical: Applied Mechanics and Materials (Volumes 105-107)
• Pages: 356-359
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.105-107.356
• Online since: September 2011
• Authors: Hai Wang Li, Cai Hong Guo, Jing Liu
• Keywords: Dynamic Response, Plastic Hinge, Steel Arch Truss, Time History Analysis

References

[1] H.W. Li, X.F. Shu and J. Liu: Proceedings of the International Association for Shell and Spatial Structures (IASS) Symposium (Spain, September 28 –October 2, 2009). p.358.

[2] GB50011-2010 The ministry of construction of the People's Republic of China: Code for Seismic Design of Buildings (China Architecture & Building Press, China 2010) p.6. (In Chinese)

[3] Golden Civil Engineering Software Technology Company in Beijing and China Building Standard Design & Research Institute: SAP2000 Chinese Guide (People's Traffic Press, China 2006) p.473. (In Chinese)

[4] GB50017-2003 The ministry of construction of the People's Republic of China: Code for Design of Steel Structures (China's Plan Press, China 2003) p.19. (In Chinese)

[5] S.S. Zhao and C. Xin: Dynamic stability of grid structure[M] (Beijing, Science Press,1999).

[6] H.W. Li, J.X. Li, F. Zhi, F. Ma and D.Q. Qin: Proceedings of the 6th International Conference on Computation of Shell and Spatial Structures IASS-IACM (Cornell University, Ithaca, NY, USA, May 28-31, 2008).

DOI: 10.1016/j.engstruct.2007.07.002
