Dynamic Characteristics Analysis of a Combined Gantry Milling Machine

Abstract:

The FE model of a combined gantry milling machine was constructed. The joint stiffness of bolt fastening, ball screw, and roller guideway were calculated. The static analysis, modal analysis and harmonic analysis of the whole machine were carried out. The results indicated that the static stiffness and minimum dynamic stiffness of the spindle could satisfy the accuracy requirements of milling, but the stiffness of the X-axis feed system was comparatively low, while the stiffness of the rest and the cross-beam could be relatively abundant. The result of “considering joint stiffness” modal analysis was more accurate than “unconsidering joint stiffness”, especially the 5th-order natural frequency had a difference of up to 52.2%. The harmonic analysis result showed that the response amplitude of the spindle center was comparatively large in three directions when the 1st-order and the 17th-order natural frequency were working, so the frequencies should be avoided while working.

• Periodical: Applied Mechanics and Materials (Volumes 105-107)
• Pages: 553-560
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.105-107.553
• Online since: September 2011
• Authors: Duan Wei Shi, Can Pei Liu, Zhi Yuan Wang, Yan Zhang, Xiao Qing Sun
• Keywords: Combined Gantry Milling Machine, Dynamic Stiffness Analysis, Finite Element Method (FEM), Joint Part

References

[1] Y.X. Song: Modeling, Identification and Simulation of Dynamics of Structures with Joints and Interfaces (University of Illinois at Urbana-Champaign, Urbana Illinois, 2004), p.125.

DOI: 10.36501/0197-9191/22-013

[2] D M Shamine, S W Hong and Y C Shin: Experimental Identification of Dynamic Parameters of Rolling Element Bearings in Machine Tools. Journal of Dynamic Systems, Measurement and Control, Trans, ASME, Vol. 122 (2000), p.95.

DOI: 10.1115/1.482432

[3] Masataka Yoshimura, Z.F. Tao translation. Use Computer-Aided Design of the Dynamic Data of the Joint Surface to Improve Structural Stiffness of the Machine. Machine Tool, (1979) No. 1, p.75.

[4] M H Mayer, L Gaul: Segment-to-Segment Contact Elements for Modeling Joint Interfaces in Finite Element Analysis. Mechanical Systems and Signal Processing, Vol. 21 (2007) No. 2, p.724.

DOI: 10.1016/j.ymssp.2005.10.006

[5] K.M. Mao, B. Li, J. Wu and X.Y. Shao: Stiffness Influential Factors-based Dynamic Modeling and Its Parameter Identification Method of Fixed Joints in Machine Tools. International Journal of Machine Tool & Manufacture, Vol. 50 (2010) No. 2, p.156.

DOI: 10.1016/j.ijmachtools.2009.10.017

[6] H.L. Tian, B. Li, H.Q. Liu, K.M. Mao, F.Y. Peng and X.L. Huang: a New Method of Virtual Material Hypothesis-based Dynamic Modeling on Fixed Joint Interface in Machine Tools. International Journal of Machine Tool & Manufacture, Vol. 51 (2011).

DOI: 10.1016/j.ijmachtools.2010.11.004

[7] B.Y. Niao, X.M. Zhou and Z.H. Yin: Modern Mechanical Dynamic and Its Application (China Machine Press, 2004), P. 232.

[8] S.Y. Jiang and S.L. Zhu: Dynamic Characteristic Parameters of Linear Guideway Joint with Ball Screw. Journal of Mechanical Engineering, Vol. 46 (2010) No. 1, p.92.

DOI: 10.3901/jme.2010.01.092

[9] C.H. Wu: Study on Axial Contact Stiffness of Ball Screws (MS., Jilin University, China 2008), p.26.

[10] WEI C C, LIN J F: Kinematic Analysis of the Ball Screw Mechanism Considering Variable Contact Deformations. Journal of Mechanical Design, Vol. 125 (2003) p.717.

DOI: 10.1115/1.1623761

[11] X.S. Jiang, K. Chong, H.F. Zhao and D.X. Guo: Dynamic Analysis of Key Parts of CNC Milling Machine Based on ANSYS. Machinery Design and Manufacture, (2009) No. 5, p.160.

[12] Y.N. Fan, Z.J. Zhang and S.P. Li: Analysis of the Dynamic Characteristics of Worktable of High-Speed Milling Machine and Its Effect on Machining Precision. Journal of ShenYang Institute of Technology, (2003) No. 9, p.9.

[13] A.F. Yuan and Q. Zhen: Modal Analysis of Miller Body Based on ANSYS. Applied Computer Technology, (2008) p.1009.
