Parametric Study on Reinforced Concrete Beams with Transversely Prestressed Bars

Abstract:

This paper presents a method that using inner transverse prestressing bars to enhance the shear capacity of concrete beams, which can be used in new transformer beams to decrease the sectional dimensions. Four transversely prestressed concrete beams and one ordinary reinforced concrete beam were tested. The nonlinear finite element method was applied to analyze them, parametric study was carried out to analyze the behavior of transversely prestressed concrete beam, and the following conclusions can be drawn: (a) With the increase of the prestressing force level, the shear capacity of transversely prestressed concrete beam increase rapidly, which means that prestressing force level has a significant effect to the shear capacity of transversely prestressed concrete beam. (b) If the area of transversely prestressing bars is almost same, the transverse bars with smaller diameter and smaller spacing can enhance shear capacity of transversely prestressed concrete beam more efficiently. (c) If steel plate of 100 mm×350 mm×16 mm being changed to steel padding of 100mm×100mm×16 mm the shear capacity of transversely prestressed concrete beam will decrease little. It means in the actual engineering the steel plate can be changed to steel padding, and then the amount of steel will be reduced.

• Periodical: Applied Mechanics and Materials (Volumes 105-107)
• Pages: 912-917
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.105-107.912
• Online since: September 2011
• Authors: Can Liu, Bo Wu, Kai Yan Xu
• Keywords: Parametric Study, Shear Capacity, Transversely Prestressed Concrete Beam

References

[1] K. Y. Zhang, L. J. Liu and Y. Liao: Research on the vertical prestress design of long-span PC continue beam bridge. Journal of Highway and transportation research and development. Vol. 21 (2004), p.45. (In Chinese)

[2] H. Huang, X. B. Tang, K. Y. Zhang and M. S. Xiang: Numerical simulation on vertical prestressed effect and experimental studies on prestressed loss. Journal of Wuhan University of Technology. Vol. 31 (2007), p.922. (In Chinese)

[3] L. Y. Chen, W. M. Wu and Y. Chen: Research on new methods for vertical prestress setting of box beam webs. Technology of Highway and Transport. Vol. 6 (2007), p.48. (In Chinese)

[4] Y. Shi, C. S. Tang, J. M. Xuan and Y. Z. Lu: Analysis of vertical prestress applied to webs of concrete box girder. Bridge construction. Vol. 1 (2006), p.8. (In Chinese)

[5] Z. Z. Zhao and A. K. H. Kwan: Nonlinear finite element analysis of deep reinforced concrete coupling beams. Engineering Structures. Vol. 26 (2004), p.13.

DOI: 10.1016/j.engstruct.2003.08.014

[6] P. Bhatt and M. A. Kader: Prediction of shear strength of reinforced concrete beams by nonlinear finite element analysis. Computers and structures. Vol. 68 (1998), p.139.

DOI: 10.1016/s0045-7949(98)00034-0

[7] H. T. Hu, F. M. Lin and Y. Y. Jan: Nonlinear finite element analysis of reinforced concrete beams strengthened by fiber-reinforced plastics. Composite Structures. Vol. 63 (2004), p.271.

DOI: 10.1016/s0263-8223(03)00174-0

[8] B. B. Adhikary and M. Hiroshi: Shear strengthening of RC beams with web-bonded continuous steel plates. Construction & Building Materials. Vol. 20 (2006), p.296.

DOI: 10.1016/j.conbuildmat.2005.01.026

[9] People's Republic of China Ministry of Construction: Steel Structure Design Specification GB50017-2003(China Building Industry Press, China 2002) . (In Chinese)
