Theoretical Analysis and Model Experimental Research on Single-Layer Hyperbolic Paraboloid Latticed Shell

Abstract:

Single-layer hyperbolic paraboloidal latticed shell dome is adopted in the gymnasium of China University of Petroleum. And the center part of the dome employs crossed web bars in order to increase stiffness of the structure. The 1:12 scale model has been made according to the construction drawings, and the mechanical properties of the model are studied under self-weight load and design load. The regularity of the members' axial force and joints' displacements are obtained. And the results show that the deflection of dome under design load conforms to the requirement of specifications, which verified the correctness of the structure design. It is found that there is no overall instability and local instability, and the behavior of the structure is almost linear.

• Periodical: Applied Mechanics and Materials (Volumes 105-107)
• Pages: 892-896
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.105-107.892
• Online since: September 2011
• Authors: Peng Deng, Lai Wang, Na Han
• Keywords: Crossed Web Bars, Model Test, Scale Model, Static Analysis

References

[1] X. Chen, N. Wang and S. Z. Shen: Experiment study on the elastic-plastic stability behaviors of hyperbolic paraboloid latticed shell. Steel Construction, Vol. 9 (1994), p.55.

[2] J. C. Xu, C.Y.Qu: Nonlinear buckling of hyperbolic parabolic double-deck reticulated shallow shells. Journal of Jinan University (Natural Science Edition), Vol.29 (2008) No.5, p.434.

[3] Y. G. Zhang: The Aseismic Characteristics for Single Layer Latticed Shell of Hyperbolic Paraboloids. Journal of Beijing Polytechnic University, Vol. 27 (2001) No.1, p.31.

[4] Y. Z. ZENG, H. W. Li, D. Q. Qin and R. J. Qian: Force analysis of single layer hyperbolic paraboloid composite latticed shell. Chinese Journal of Computational Mechanics, Vol.18 (2001) No.1,p.37.

[5] T. Lan, J.D. Zhao: Roof structure of hyperbolic paraboloid recticulated shell sfor the gymnasium of Beijing institute of physical education. China Civil Engineering Journal, Vol. 25 (1992) No. 6, 1992, p.10.

[6] S. Z. Shen, N. S. Gu: Combined latticed shell roof structure of gymnasium for 11th Asian Games. , Journal of Building Structures, Vol. 11 (1992) No. 1, p.21.

[7] Z. Y. Shen, X. Z. Zhao, Y. Y. Chen and Y. G. Chen: Some key technics for a static test of overall model if super spatial structures. China Civil Engineering Journal, Vol.34 (2001) No. 4, p.102.

[8] Y. Wang, X. S. Wang, Z. Y. Zhu, W. H. Qi and S. Zhou: Design and research for main roof of Gymnasium of China University of Petroleum (Qingdao Campus)., Building Structure. Vol. 39 (2009) No. 12, p.71.
