Numerical Analysis on Impact Behavior of Composite Sandwich Plates as Energy Harvesting Structures

Abstract:

There are two approaches to design high energy absorbing materials and structures: one is to optimize the structures by using ordinary materials. The other is to design new energy absorbing materials. The efficiency of energy absorbing structures is continuously improved by developing various types of structural geometries and selecting appropriate energy absorbing materials like polymeric foams or metallic foams. Because of composite materials which are used in these kinds of structures, too many useful properties are achieved, for example, light weight, high energy absorption, high stiffness, fracture toughness. In this study, different composite sandwich structures are modeled by ABAQUS FE software. The model is validated by the results in existed literature. Different materials as core and as face sheets in the composite sandwich structure are investigated. Internal energy and displacement of the structure during the impact analysis in low velocity are calculated. By changing variables and parameters such as dimensions of the structure, different properties and sequences of the layers in the face sheets and different core materials, the optimum state of the structure for gaining the highest internal energy is determined. By increasing the size of the structure and using the stiffer fibers, the absorbed energy is increased. The effect of stiffer core in increasing absorbed energy is more significant. The layer sequencing does not affect any changes in the absorbed energy.

• Periodical: Applied Mechanics and Materials (Volumes 110-116)
• Pages: 1296-1304
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.110-116.1296
• Online since: October 2011
• Authors: Sameera Khalili, Seyyed Mohammad Reza Khalili, M. Amidpour
• Keywords: ABAQUS, Composite Sandwich Plate, Energy Absorption, Energy Harvesting, Impact

References

[1] A. Khaligh, Omer C. Onar, Energy Harvesting: Solar, Wind, and Ocean Energy Conversion Systems, CRC Press (2010).

DOI: 10.1201/9781439815090

[2] Y. Zhaoa, M. Taya, H. Izui, Study on energy absorbing composite structure made of concentric NiTi spring and porous Ni Ti, International Journal of Solids and Structures, 43 (2006).

DOI: 10.1016/j.ijsolstr.2005.06.043

[3] H. Mahfuz, T. Thomas, V. Rangari, Sh. Jeelani, On the dynamic response of sandwich composites and their core materials, Composites Science and Technology, 66 (2006).

DOI: 10.1016/j.compscitech.2006.02.020

[4] T. Anderson, E. Madenci, Experimental investigation of low-velocity impact characteristics of sandwich composites, Composite Structures 50 (2000).

DOI: 10.1016/s0263-8223(00)00098-2

[5] P. M. Schubel, J. Luo, I. M. Daniel, Low velocity impact behavior of composite sandwich panels, Composites: Part A 36 (2005).

DOI: 10.1016/j.compositesa.2004.11.014

[6] T.A. Anderson, An investigation of SDOF model for large mass impact on sandwich composite, Composites: Part B 36 (2005).

[7] R. H. Zee, Chung, Y. Hsieh, Energy absorption processes in fibrous composites, Materials Science and Engineering, A246 (1998).

[8] D.G. Lee, T. S. Lim, S. S. Cheon, Impact energy absorption characteristics of composite structures, Composite Structures 50 (2000).

DOI: 10.1016/s0263-8223(00)00117-3

[9] Seong Hwan Yoo, Seung Hwan Chang An experimental study on energy absorbing structures made of fabric composites, Composite Structures 86 (2008).

DOI: 10.1016/j.compstruct.2008.03.010

[10] P. Arnaud & P. Hamelin, Dynamic Characterization of Structures: A Study of Energy Absorption in Composite Tubes, PII: SO266-3538 (1997).

[11] S. Nemat-Nasser, W.J. Kang, J.D. McGee, W.G. Guo, J.B. Isaacs, Experimental investigation of energy-absorption characteristics of components of sandwich structures, International Journal of Impact Engineering, 34 (2007).

DOI: 10.1016/j.ijimpeng.2006.05.007

[12] T. Anderson, E. Madenci, Graphite/epoxy foam sandwich panels under quasi-static Indentation, Engineering Fracture Mechanics, 67 (2000).

DOI: 10.1016/s0013-7944(00)00066-7

[13] G. R. LIU, X. Q. PENG, K. Y. LAM, Vibration control simulation of laminated composite plates with integrated piezoelectrics, Journal of Sound and Vibration, 220 (5), (1999).

DOI: 10.1006/jsvi.1998.1970
